A Compact Extension at the Heart of the AudioFuse Ecosystem
The AudioFuse X8 IN is the perfect complement to audio interfaces equipped with ADAT inputs, providing additional line channels without the complexity of a full interface. Its half-rack chassis and mounting accessories allow aligning two units for a total of 16 line inputs in a single 1U space, while maintaining a neat and scalable setup.
Designed for Hybrid Studios and Synth Collectors
Producers, sound engineers, and musicians with multiple instruments will find a simple solution here to keep everything plugged in and ready to record in the DAW. Whether capturing a modular synth set, standardizing a machine collection, or integrating external effects, the X8 IN offers clean connectivity and solid synchronization via Word Clock.
Technical specifications
| Type of local inputs | Balanced line | Power supply | DC 15 V |
| Sampling frequency | 96 kHz | Weight | 1.41 kg |
| Color | Black | ||
Questions frequently asked
Is the Arturia AudioFuse X8 IN compatible with an ADAT interface?
Both ADAT optical outputs transmit the 8 line inputs to an interface equipped with ADAT inputs. SMUX support allows operation up to 96 kHz by distributing the channels across the ADAT streams.
How many synths can be connected to this expansion unit?
Eight line-level sources can be connected via the balanced 6.3 mm jack inputs. Two units can be mounted side by side to reach 16 line inputs in a 1U rack space.
Can the expansion be synchronized with an external clock?
A Word Clock input in BNC format ensures locking to an external clock. This synchronization stabilizes the digital stream between the expansion and the rest of the setup. The AKM A/D conversion is performed at 24 bits up to 96 kHz.
What controls are available on the front panel?
The front panel offers channel selection, a Link function to group pairs, and a colored LED meter to visualize levels.
Is the format suitable for rack installation?
The black half-rack 1U chassis weighs 1.41 kg and comes with mounting accessories. The external power supply operates at 15 V DC.
