FBT Install Archon 115 Black

Name: Archon 115 Black
Brand: FBT Install
SKU: 422563
Price: 1399.00 EUR
Availability: InStock

1.399,00 €VAT incl.

3,00 € Ecotax included

Reference price

Available on order

Store: on order

Estimated Shipping Widget will be displayed here!

ID : 422563

EAN : 8034138362558

FBT Install

This item is covered for 3 years

Information

Essential Information About the FBT Install Archon 115 Passive Sound Reinforcement Speaker
• High efficiency and strong acoustic pressure : 100 dB sensitivity and peak max SPL up to 134 dB to cover demanding spaces.
• Versatile 15-inch format : solid bass, present low-midrange, and effective projection for front fill, vocal reinforcement, or amplified music.
• Controlled dispersion : constant directivity rotatable horn with 60 deg (H) x 40 deg (V) dispersion to adapt orientation to the venue.
• Reliable installation : Baltic birch plywood enclosure, steel grille, multiple rigging points, and professional connectors (Speakon NL4 + Euroblock).

Archon 115 Black

1.399,00 €VAT incl.

3,00 € Ecotax included

Reference price

Archon: a speaker designed for installation and consistent coverage

The FBT Install Archon 115 is designed with a fixed installation sound reinforcement approach: a robust passive speaker made to integrate neatly into a fixed or semi-fixed system while maintaining performance levels suited for professional environments. Its 2-way configuration combined with a constant directivity horn aims for even coverage and stable intelligibility, a key point when sound reinforcing a room without "hot" or "dead" zones.

Within a range dedicated to integration, this 15-inch model holds a strategic position: it combines the necessary presence for music and impact for dynamic programs while remaining precise enough for vocals. The result is a black, understated speaker designed to last and remain consistent in mono, stereo, or multi-zone setups.

Intended uses and target profiles

The Archon 115 is tailored for service providers and integrators seeking a passive speaker capable of handling demanding use with flexible deployment: front fill in bars, clubs, or small stages, versatile room reinforcement, places of worship, auditoriums, community halls, event spaces, or fixed installations requiring secure rigging points.

Thanks to its 15-inch driver and 500 W RMS power, it suits both musical reproduction and speech reinforcement when projection and solid low-end performance are expected. It can be pole-mounted via a 35 mm socket, suspended using its M10 points, or positioned according to venue constraints.

Technical specifications

Bluetooth

Questions frequently asked

Which amplifier should be used with the FBT Install Archon 115 Black speaker?

The recommended amplification is 1000 W RMS at 8 ohms. The speaker can handle a peak power of 2000 W and has a sensitivity of 100 dB.

Can the Archon 115 operate in bi-amplification mode?

The crossover can operate in passive mode or Bi-Amp mode, with a crossover frequency set at 1.3 kHz. Bi-amplification allows separate control of the drivers through a suitable architecture. A high-pass filter at 35 Hz with a 24 dB/oct slope is recommended.

How to suspend an FBT Archon 115?

Suspended installation is done via 12 threaded M10 rigging points, while a 35 mm socket allows pole mounting.

What dispersion does the rotatable horn offer?

The constant directivity horn covers 60° horizontally and 40° vertically. Its rotation allows adapting this coverage to the speaker’s orientation.

What connections are available on this passive speaker?

The connectivity includes two Speakon NL4 connectors for input and link, as well as a Euroblock connector. The enclosure is made of 15 mm Baltic birch plywood and protected by a steel grille with dust cloth.
