Macro Power S12: a solution at the core of the MOOER power supply range
With the Macro Power S12, MOOER offers a power supply designed to centralize the energy of a complete pedalboard, while maintaining a "stage-oriented" approach: compact format, metal chassis, and current distribution designed to meet the varied needs of today's pedals. It naturally fits into a setup where you want to limit individual power supplies, secure wiring, and gain stability in daily use.
For which guitarists and bassists?
This power supply is aimed at musicians who use multiple pedals and want a clean, practical, and coherent solution: rehearsals, studio, live performances, or well-organized home studios. Thanks to its multiple 9V outputs and various available current levels, the Macro Power S12 suits both "classic" pedalboards (compressors, drives, modulations) and more modern setups incorporating current-hungry digital effects.
A power supply designed for a stable and versatile pedalboard
12 outputs to cover the essentials of a pedalboard
The MOOER Macro Power S12 provides 12 outputs, mainly at 9V, with currents adapted to different types of pedals. The 200 mA outputs are perfectly suited for many analog effects and a large portion of standard pedals, while the 300 mA and 500 mA outputs provide the necessary margin for digital effects, some compact multi-effects, or pedals with higher power consumption.
Selectable voltage output: a real plus for specific pedals
The presence of a selectable voltage output (9/12/15/18V) allows covering particular needs without adding an external accessory. This is ideal for users who switch between several pedals or want to evolve their board: you keep a single power supply and adjust the voltage according to the pedal used.
Design and safety: reliability on stage and in the studio
The Macro Power S12 relies on 2 independent toroidal transformers and integrates surge protection to enhance overall reliability and safeguard your gear. The 220/110V switch offers appreciated flexibility depending on the usage context, while the metal casing is designed to withstand the stresses of transport and pedalboard installation.
Delivered with its cables and a velcro strap, it integrates quickly into your setup: you install, power up, and focus on what matters most - your sound.
Technical specifications
| Category | Multiple power supply |
| Number of outputs | 12 |
| 6 outputs at 9V | 200 mA each |
| 3 outputs at 9V | 300 mA each |
| 2 outputs at 9V | 500 mA each |
| 1 selectable voltage output | 9/12/15/18V, 300 mA |
| Mains power switch | 220/110V |
| Dimensions | 225 x 88 x 50 mm |
| Weight | 1.82 kg |
Questions frequently asked
How many pedals can the Mooer Macro Power S12 power?
This power supply has 12 outputs: six at 9 V / 200 mA, three at 9 V / 300 mA, two at 9 V / 500 mA, and one selectable output. It allows centralizing the power supply for a complete pedalboard.
Which outputs are suitable for power-hungry digital pedals?
The two 9 V / 500 mA outputs provide the highest current reserve. Three 9 V / 300 mA outputs are also available for pedals requiring more current than standard pedals.
Can a pedal be powered at 12 V, 15 V, or 18 V?
One 300 mA output can be set to 9 V, 12 V, 15 V, or 18 V. The voltage must match the specifications of the connected pedal.
Is the power supply suitable for a stage pedalboard?
The metal enclosure is designed for transport and installation on a pedalboard. Two independent toroidal transformers and surge protection contribute to the power supply's reliability. A Velcro strip and the necessary cables are included.
What are the dimensions and weight of this power supply?
Measuring 225 x 88 x 50 mm and weighing 1.82 kg, this model features a size intended for pedalboard integration.
