A USB-C interface designed for the club and the Serato ecosystem
Designed by Reloop, the FLUX transforms any mixer into a professional digital vinyl system. Robust, compact, and performance-oriented, it integrates effortlessly with setups featuring turntables, CDJs, or media players, while offering the finish and ergonomics expected by club DJs and sound technicians.Who is it for and what are its uses?
The FLUX is aimed at vinyl DJs, turntablists, club residents, and mobile providers who want the reliability of a Serato DVS on their turntables. It is also suitable for studio and quick recordings thanks to its standalone audio interface mode, as well as for fixed installations requiring a clean, stable, and easily supervised solution.Features and new additions
With its three stereo channels switchable via DIP switches, the FLUX accepts phono, line signals, or an AUX-IN for a live source in any combination. The analog bypass buttons allow instant switching back to vinyl/CD "Thru" playback. LED indicators per input/output (L/R), power status display (Hub, PD, DC), and gold-plated connectors secure your shows. On the connectivity side, the 2-port USB-A hub simplifies accessory connections, while USB-C with Power Delivery (up to 60 W) powers your computer and setup. Compatible with "Serato NoiseMap" control vinyl (not included) or a timecode WAV file for CD/USB stick, no additional license purchase is required for DVS use.Technical specifications
| Compatibility | Mac, Serato DJ | Outputs | Stereo audio, Auxiliary RCA |
| Inputs | phonograph, line, auxiliary RCA | ||
| Recommended power | 2 A or more; minimum power: 400 mA. | THD+N - LINE input | -4 dBV at 1 kHz, < 0.03% (1 kHz, 0 dB); PHONO input: -36 dBV at 1 kHz, < 0.05% (1 kHz, 0 dB, inverse RIAA). |
| Maximum USB-PD throughput | 60 W. | Maximum gain - Deck In LINE | +4 dB +/- 2 dB; Deck In PHONO: +36 dB +/- 2 dB. |
| Maximum USB hub output power | 2 x 0.8 A = 8 W. | Maximum input (1 kHz, THD = 1%) - LINE | > +7 dBV; PHONO: > -25 dBV. |
| Supported external USB power (Type A or C) | 5 V/1 A up to 20 V/3 A. | Maximum output (1 kHz, THD = 1%) - Deck output | > +11 dBV. |
| Power priority | FLUX self-powering -> USB Hub -> PD (to PC). | Dimensions (W x D x H) | 160 x 120 x 34 mm. |
| Signal-to-noise ratio (1 kHz, +4 dB) - Deck In LINE (0 dBV) | > 83 dB; Deck In PHONO (-32 dBV): > 73 dB. | Weight | 0.85 kg. |
Questions frequently asked
Is the RELOOP DJ Flux compatible with Serato DJ on Mac?
The interface is compatible with Serato DJ on Mac. DVS use does not require an additional license with Serato NoiseMap vinyls not included or a timecode WAV file.
Can turntables be connected to this DVS interface?
The three stereo inputs can be switched via DIP-switches to phono or line level. An AUX-IN input also allows connection of a live source. The Thru buttons provide instant feedback to vinyl or analog CD playback.
Can the USB-C port power a laptop?
The USB-C port supports Power Delivery up to 60 W to the computer. Two USB-A ports deliver up to 0.8 A each, for a maximum total power of 8 W. External power supplies from 5 V/1 A up to 20 V/3 A are supported.
Can the FLUX function as a standalone audio interface for recording?
The standalone audio interface mode allows quick recordings without using DVS.
What audio performance is specified for the line and phono inputs?
On the line inputs, the signal-to-noise ratio exceeds 83 dB at 1 kHz and the THD+N distortion remains below 0.03%. On phono, the signal-to-noise ratio exceeds 73 dB and the THD+N is under 0.05%.
