A Power Supply Designed for Modern Pedalboards
The RockBoard ISO Power Block V6 follows a "pedalboard-ready" approach: multiple isolated outputs, a compact format, and standardized connectors. The goal is simple: centralize the power supply for your effects while minimizing noise often associated with non-isolated power blocks.
Who Is It For and What Is It Used For?
This power supply is aimed at guitarists and bassists who use multiple pedals (overdrive, delay, modulation, preamp, etc.) and want a clean, reliable, and easy-to-integrate solution under or on a pedalboard. It is also well suited for hybrid setups thanks to its high current capacity outputs.
Filtering, Isolation, and Daisy-Chaining: The Essentials Without Compromise
Isolated and Filtered Outputs
Each socket is isolated and filtered to reduce interactions between pedals and improve stability, especially with more demanding digital effects.
Series Expansion via 18V
The 18V DC output allows connecting multiple ISO Power Block V6 units in series to expand your pedalboard without changing the power supply system.
Technical specifications
| Current | 2.5 A | Category | Multiple power supply |
| Voltage | 18 V | Number of outputs | 5 |
| Total output load | 22.5 W, 2,500 mA | Dimensions | 120 x 70 x 25 mm |
| Input voltage | 18V DC | Weight | 175 g |
| AC range | 100-240V AC | ||
Questions frequently asked
How many isolated outputs are available?
All five outputs are isolated and filtered to minimize interactions between pedals.
Is this power supply suitable for power-hungry digital pedals?
With a total load capacity of 2,500 mA and 22.5 W, this power supply is designed for setups including demanding digital effects. The current distribution across outputs is not specified.
RockBoard POWER-block-ISO6: is it possible to daisy chain multiple units?
Thanks to the 18 V DC output, multiple ISO Power Block V6 units can be connected in series. This feature allows expanding a pedalboard without replacing the power system. The unit's input also operates at 18 V DC.
What are the dimensions of the power supply?
Its size of 120 x 70 x 25 mm and weight of 175 g make it easy to integrate on or under a pedalboard.
Is the power supply compatible with international mains voltages?
The specified mains range of 100 to 240 V AC allows use with various mains voltages.
