Allen & Heath QU-pac

A Direct Successor to the GLD, Designed for Compact Installations

The Qu series continues the legacy of Allen & Heath GLD consoles by adopting the fundamentals of modern digital mixing: full recall of settings, comprehensive processing on each channel, and I/O remote capabilities to suit both stages and fixed installations. With the Qu-Pac, this approach becomes even more accessible thanks to a 19" rack format that retains the "pro" DNA of the range: fast workflow, secured access, and simple integration into environments where space and reliability are priorities.

A Mixer Made for Bands, Public Venues, and "Stress-Free" Control Rooms

The Qu-Pac is aimed at music bands, schools, hotels, multipurpose rooms, corporate assemblies, and any context requiring a professional mixing solution in a small footprint. Its approach is ideal when the mixer needs to remain discreet (in a rack, technical control room, or furniture) while allowing full control via the touchscreen or on the move. User permission functions and Qu-Control customization make daily operation smoother, even when handled by non-technical personnel.

Technical specifications

Scene memory recall	Yes	Recording	qu-drive: stereo (LR) and 18-track multitrack
Number of channels	22	Busses / groups	16 bus
Phantom power supply	Yes	Compressor / gate	on all inputs and outputs
Bluetooth	No	Number of auxiliary sends	12
Remote control	tablet (router not included)	Mic inputs	16 x XLR
EQ	4-band parametric on all inputs	Line inputs	16 mono + 3 stereo (2 jack + 1 minijack)
Motorised faders	No	Inputs (other)	talkback (XLR)
PFL/AFL mode	Yes	Main outputs	2 x XLR
Rackable	No	Outputs (other)	2 x stereo matrixes (4 XLR), 2 x tracks (2 jacks), alternate (2 jacks), dSnake for digital mixracks, mixes: 4 mono + 7 XLR stereo, AES digital
Rack unit	4	Color	Black
Category	digital mixer	Built-in effects	Yes
Graphic equalizer	1/3 octave	Display	5 "color touch screen
Number of matrixes	2	Weight	6.6 kg
Number of mic preamps	16	Dimensions (mm)	440 x 180 x 181
