Allen & Heath ZEDI-10FX
Estimated Shipping Widget will be displayed here!
- This item is covered for 3 years
What you need to know
What you need to know
- Hybrid design: a robust analog mixing top with an integrated 24-bit/96 kHz USB audio interface, ideal for multitrack recording.
- Ultra-low-noise GSPre preamps, 3-band MusiQ EQ, and an integrated effects engine (reverbs, delays, FX) with tap tempo.
- Versatile connectivity: 4 mono channels, 2 stereo channels, 2 high-impedance guitar inputs, XLR and auxiliary outputs for monitoring.
- Ready for creating: supplied with Cubase LE to record, edit, and mix your projects on a computer or iPad.
Manufacturer Information
Allen&Heath
https://www.allen-heath.com
------------------------
Safety manager:
Algam SAS
Email: contact@algam.net
Address:
Essential Information About the Allen & Heath ZEDi-10FX Analog Mixer
- Hybrid Design: robust analog mixer with built-in 24-bit/96 kHz USB audio interface, ideal for multitrack recording.
- GSPre ultra-low noise preamps, 3-band MusiQ EQ, and built-in effects engine (reverbs, delays, FX) with tap tempo.
- Versatile Connectivity: 4 mono channels, 2 stereo channels, 2 high-impedance guitar inputs, XLR and auxiliary outputs for monitors.
- Ready for Creation: comes with Cubase LE to record, edit, and mix your projects on computer or iPad.
The ZEDi-10FX, Heir to the ZED Series
Designed in the tradition of Allen & Heath consoles, the ZEDi-10FX carries forward the reliability and warm analog sound that made the ZED series renowned, while integrating the best of digital technology. Its all-in-one approach makes it a compact and durable solution for musicians, project studios, and small live setups.
Who Is It For and What Are Its Uses?
The ZEDi-10FX is aimed at singer-songwriters, rehearsal bands, mobile sound engineers, and content creators seeking a simple workflow. It excels for home studio, lightweight live sets, streaming, or multitrack recording without the hassle of an external interface.
Technical specifications
| Number of faders | 0 | Number of mic preamps | 4 |
| Number of channels | 10 | Number of auxiliary sends | 1 |
| Phantom power supply | Yes | Mic inputs | 4 x XLR |
| Bluetooth | No | Line inputs | 2 x stereo, 4 x jack |
| EQ | 3 channels | Inputs (other) | USB |
| Motorised faders | No | Main outputs | 2 x XLR |
| Filters | Low cut | Outputs (other) | USB, Aux jack, FX jack, monitor Rca |
| Provided software | Cubase LE | Color | Grey |
| PFL/AFL mode | Yes | Built-in effects | Yes |
| Rackable | No | Display | LED and backlit display |
| Category | analog mixer | Weight | 2.3 kg |
| Fader travel | 60 mm | Dimensions (mm) | 332,9 x 274,6 x 96,5 |
| Integrated effects | yes (tap tempo) | Included software | Cubase LE |
| Mic/line inputs | 4 with separate XLR and 6.35 mm TRS jack connectors | Included application | Cubase LE |
| Stereo inputs | 2 on 6.35 mm TRS jacks | Phantom power for condenser microphones | yes |
| Guitar D.I. inputs | 2, high impedance | Power supply | internal |
| Signal level bargraph | 8 LEDs | Weight (kg) | 2.30 |
| Headphone output | 6.35 mm jack | ||
You will also like
Yamaha
MG10XU
Zoom
Livetrak L6
Yamaha
MG10xuf
Mackie
Onyx 8
Behringer
Xenyx QX2442USB
Midas
DM16
Yamaha
MG12
Behringer
Xenyx QX1832USB
Customer reviews
Based on 4 reviews
- 5 stars, 1 review
- 4 stars, 3 reviews
- 3 stars, 0 reviews
- 2 stars, 0 reviews
- 1 star, 0 reviews
The review form didn't open. Please try again.
-
We won't give 5 stars for the plastic case (but sturdy) and the flashy sticker beautifully glued to the facade does not reflect the best of made in China. After the slightly confusing design of the object, the potentiometers are quite firm and the promise of a hybrid machine has been fulfilled. We have both an analog mixer with built-in effects and its stereo output, and at the same time the ability to record 4 channels in parallel in real time via the USB output (tested on an old Macbook with Audacity while waiting to buy me a modern UC and install Cubase with the license included). You can also record the sound of a “dry” microphone and that worked by the effects generator in parallel. Then I would have to compare the acquisition with an equivalent Focusrite box, but I didn't really like having to systematically do everything with the mouse on the screen. So in the end, a real alternative to a 4X4 interface whose pleasure of use is not compromised by a design that is not its best asset. As far as I know, it is also the only machine with these capabilities.
Automatically translated
-
We won't give 5 stars for the plastic case (but sturdy) and the flashy sticker beautifully stuck with Traviola on the facade does not refer to the best of made in China. After the slightly confusing design of the object, the potentiometers are quite firm and the promise of a hybrid machine has been fulfilled. We have both an analog mixer with built-in effects and its stereo output, and at the same time the ability to record 4 channels in parallel in real time via the USB output (tested on an old Macbook with Audacity while waiting to buy me a modern UC and install Cubase with the license included). You can also record the sound of a “dry” microphone and that worked by the effects generator in parallel. Afterwards, I would have to compare the acquisition with an equivalent Focusrite box, but I didn't really like having to systematically do everything with the mouse on the screen. So in the end, a real alternative to a 4X4 interface whose pleasure of use is not compromised by a design that is not its best asset. As far as I know, it is also the only machine with these capabilities.”
Automatically translated
-
I have had this table for over a year. I find its rendering really classy especially compared to my first Phonic table. If I had a new choice, it would be the same with one or two more entries. I only gave 4 stars because I am having some problems connecting ZEDI/CUBASE. There is a parameter that I am missing and I cannot link table to computer via USB.
Automatically translated
-
I was able to compare with an old Yamaha mixer.
There is no photo.
The sound is very clear. No breath.
When you buy this Allen & Heath brand, you will have no regrets.Automatically translated
No reviews match this filter.
Reviews can't be loaded right now. Please try again.
Automatically translated
Questions frequently asked
Can the Allen & Heath ZEDi-10FX record multitrack?
The built-in USB interface provides 24-bit/96 kHz audio transfer to a computer. Cubase LE software is included for multitrack recording, editing, and mixing.
How many microphones can be connected to this mixer?
Four XLR microphone inputs are paired with four GSPre preamps. Phantom power is available for condenser microphones.
Can guitars be connected without a DI box?
Two high-impedance guitar inputs allow direct connection of instruments, without an external DI box.
What effects are available on the ZEDi-10FX?
The internal effects engine offers reverbs, delays, and special effects. A tap tempo control allows adjusting the effect tempo.
What output connections are provided for live and monitoring?
The main outputs are stereo XLR. An AUX send on a jack can feed a stage monitor or in-ear monitors. A 6.35 mm headphone jack and RCA monitor outputs complete the monitoring options.
