AlphaTheta DJM-V5
Estimated Shipping Widget will be displayed here!
- This item is covered for 3 years
Essential Information About the DJ Mixer DJM-V5
Essential Information About the DJ Mixer DJM-V5
- Compact format inspired by the DJM-V10, featuring 60 mm long-throw faders for ultra-precise level control
- 4-band EQ, compressor per channel, 3-mode filters (low-pass, high-pass, cross-pass), and dedicated Send FX
- High-resolution audio thanks to the 96 kHz / 64-bit DSP and 32-bit ESS converters on inputs/outputs
- Extensive connectivity USB-C (rekordbox, Serato DJ Pro), MULTI I/O, USB send/return, and integrated SonicLink
Manufacturer Information
AlphaTheta
https://www.alphatheta.com
------------------------
Safety manager:
AlphaTheta EMEA Limited Belgiu
Email: service@alphatheta.com
Address:
The Heritage of a Club Standard
Direct heir to the ergonomics and "feel" of the DJM-V10, the DJM-V5 condenses this philosophy of broad, musical mixing into a chassis approximately 30% more compact. It features an architecture designed to layer multiple sources without distortion, with a clean stereo image and comfortable headroom, tailored for clubs, studios, stages, or fixed installations.Who Is the DJM-V5 For?
Ideal for club DJs, hybrid performers, live beatmakers, and content creators, the DJM-V5 excels in layered sets: solid kick, stems, drum machines, and external effects. The 60 mm faders enable precise fades, while the 3-position filters and per-channel effects send offer immediate expression, whether solo, back-to-back, or in live setups.Technical specifications
| Type | Digital | Number of faders | 3 |
| USB stereo recording / playback | Yes | Rackable | No |
| Compatibility | rekordbox for Mac/Windows | HEADPHONE MONITOR outputs | 2 (1 x 6.35 mm stereo jack, 1 x 3.5 mm stereo mini-jack) |
| Frequency response | 20 Hz - 40 kHz (LINE) | REC output | 1 (RCA) |
| Signal-to-noise ratio | 110 dB (USB), 105 dB (LINE), 88 dB (PHONO), 79 dB (MIC) | USB ports | 2 Type-C (rear and top panel, MULTI I/O) |
| Total harmonic distortion | 0.005 % (LINE - MASTER) | LINK port | 1 (LAN) |
| Processing | 96 kHz / 64-bit DSP, 32-bit ESS A/D and D/A converters | USB send/return | for external processors |
| LINE inputs | 3 (RCA) | Frequency band used | 2.4 GHz |
| PHONO inputs | 3 (RCA) | Direct pairing | dedicated button (HDJ-F10 and models scheduled for 2026) |
| RETURN input | 1 (6.35 mm TS jack) | Dimensions (W x D x H) | 302.0 x 437.5 x 107.9 mm |
| BOOTH output | 1 (6.35 mm TRS jack) | Weight | 8.0 kg |
| SEND output | 1 (6.35 mm TS jack) | Included accessories | power cord, quick start guide, precautions for use, warranty (depending on region) |
You will also like
Allen & Heath
Xone:96
Pioneer Dj
DJM-S11
Pioneer Dj
DJM-S7
Union Audio
ELARA.4 MK2 4-CH Desktop DJ-Mixer
Union Audio
TWO.VALVE Rotary Desktop Mixer
Rane DJ
Seventy
Allen & Heath
Xone 92 MK2
Pioneer Dj
DJM-750 MK2
Questions frequently asked
Is the DJM-V5 compatible with rekordbox and Serato DJ Pro?
Compatibility with rekordbox for Mac/Windows is announced. Serato DJ Pro can also be used, with a license required.
What Send FX effects are available on this mixer?
Six Send FX are integrated: Short Delay, Reverb, Shimmer, Tape Echo, PingPong, and Echo-Verb. A send knob is present on each channel to control the send level to the selected effect.
Can a wireless headphone be used with the DJM-V5?
The built-in SonicLink allows direct 2.4 GHz pairing with the HDJ-F10 headphones via a dedicated button.
What is the audio quality and sampling frequency?
Processing is based on a 96 kHz / 64-bit DSP and 32-bit ESS A/D and D/A converters. The LINE frequency response ranges from 20 Hz to 40 kHz, with a signal-to-noise ratio of 105 dB on the LINE input. The total harmonic distortion between LINE and MASTER is specified at 0.005%.
Is the DJM-V5 suitable for a live setup with multiple sources?
Its three 60 mm faders and dedicated low-pass, high-pass, or cross-pass filters facilitate layered mixing. The USB send/return and MULTI I/O allow integration of an external effects processor.
