Blackmagic Design Mini Converter - SDI Distribution

Name: Mini Converter - SDI Distribution
Brand: Blackmagic Design
SKU: 425997
Price: 179.00 EUR
Availability: InStock

179,00 €VAT incl.

0,90 € Ecotax included

Reference price

Available on order

Store: on order

Estimated Shipping Widget will be displayed here!

ID : 425997

EAN : 9338716001235

This item is covered for 3 years

Information

Essential Information About the SDI Distribution Mini Converter
• 1 SD/HD/3G-SDI input with automatic detection, replicated to 8 synchronized SDI outputs to feed multiple devices without loss of coherence.
• Compatible up to 1080p60 and 2K DCI formats via 3G-SDI Level B, ideal for most HD and 2K cinema chains.
• Transports the essentials of a broadcast signal: embedded audio, auxiliary data, and support for ASI streams.
• Easy integration in racks or flycases: 12 V universal power supply included and wide power range for both fixed installations and field use.

Mini Converter - SDI Distribution

179,00 €VAT incl.

0,90 € Ecotax included

Reference price

A Mini Converter Designed for SDI Distribution in Professional Environments

The Mini Converter SDI Distribution is part of the Mini Converter range, designed to meet the demands of broadcast and live production: stability, quick setup, and reliable daily operation. Its mission is clear: to take a single SDI source (SD, HD, or 3G-SDI) and cleanly duplicate it to eight outputs, maintaining an identical signal across the entire control room. It is a relevant solution when working in SD, HD, or 2K without the need for Ultra HD, and when you want a clean, readable, and standardized distribution.

A 1x8 SDI Distributor for Control Rooms, Studios, and Streaming

This distribution converter is intended for studios, TV sets, OB vans, theaters, houses of worship, and streaming setups relying on an SDI infrastructure. It allows simultaneous feeding of a video mixer, monitoring monitors, a recorder, additional converters, or routers, while keeping synchronized outputs to facilitate operation. In practice, it becomes a central point in workflows when multiple operators or machines need to access the same master without patchwork or risky splitting.

Technical specifications

Accessories included	External power supply	Outputs	8x SDI
Category	Distributor	Power supply	External power supply
Requires power supply	Yes	Consumption	4.8 W
Maximum conversion resolution	1080p	Weight	240 g
Type	Video	Dimensions (mm)	122x92x23
Inputs	1x SDI

Questions frequently asked

How many SDI monitors or devices can be powered simultaneously?

One SDI input is distributed to 8 SDI outputs, all automatically matching the incoming signal. This setup allows powering, for example, a switcher, monitoring screens, and a recorder from the same source.

Does the Blackmagic Design Mini Converter SDI Distribution support 1080p60?

Supported formats include 1080p60, as well as 1080p50, 1080i, and many progressive or PsF frame rates. The maximum supported resolution is 1080p.

Is embedded audio preserved on the SDI outputs?

Auxiliary streams and embedded SDI audio are supported, with audio sampling at 48 kHz in 24-bit.

Is this SDI distributor compatible with 2K DCI signal?

2K DCI compatibility is ensured via 3G-SDI level B at 23.98p, 24p, and 25p frame rates, including PsF. Both YUV and RGB color spaces are supported, with video sampling of 4:2:2 or 4:4:4. ASI streams are also accepted.

What power supply should be used for this SDI distributor?

A universal 12 V power supply with international adapters is provided. The operating range extends from 12 to 31 V DC with a power consumption of 4.80 W.
