A compact format designed for the essentials of the GEM range
The Gemini GEM-08USB embodies the spirit of small analog mixing consoles focused on versatility: multiple inputs, direct control via potentiometers, and practical functions for playback and live performance. Its compact size makes it easy to integrate on a desk, mobile rig, home studio corner, or improvised rack, while maintaining immediate access to the most important controls.
Who is the Gemini GEM-08USB for?
This mixer is particularly suited for content creators, podcasts, rehearsals, and small gigs that need to connect multiple sources without complexity: microphones, keyboards, stereo audio players, or computer returns. Bluetooth simplifies streaming a backing track or ambiance, while the headphone output with dedicated volume allows precise monitoring even in noisy environments.
Sound control and creativity: EQ, effects, and routing
3-band equalizer per channel: a clear and balanced mix
Each channel features a 3-band equalizer with dedicated volume control, convenient for quickly correcting a too-bright vocal, overpowering bass, or creating space between instruments. The specified action points (high at 12 kHz and low at 80 Hz) cover key areas of tone and foundation for a clearer sound without external processing.
16 internal effects: depth without external gear
To add depth to a vocal or character to an instrument, the GEM-08USB includes 16 effects. The effects send on each channel allows adjusting the effect level per source, while the pan control helps organize the stereo field naturally. The result: a livelier, more "finished" mix with quick and intuitive setup.
Everyday useful connectivity: stereo, 2TK, and REC
With 8 standard inputs in total, including 2 balanced MIC/LINE inputs and 4 stereo inputs, the console covers most common needs. The 2TK input and REC output simplify adding a dedicated playback source and capturing a signal for recording. The two-level LED indicators help quickly monitor levels and avoid clipping, while the headphone output with dedicated volume secures monitoring.
Technical specifications
| Type | analog Compact |
| USB stereo recording / playback | Yes |
| Number of faders | 9 |
| Rackable | No |
| Headphone output | Yes |
| Standard inputs | x8 |
| Balanced MIC/LINE inputs | x2 |
| Stereo inputs | x4 |
| Microphone preamps | x2 |
| Phantom power | yes |
| Equalizer | 3 bands per channel |
| 𝗣𝗮𝗿𝗮𝗺𝗲𝘁𝗿𝗶𝗰 𝗲𝗾𝘂𝗮𝗹𝗶𝘇𝗲𝗿 (𝗳𝗿𝗲𝗾𝘂𝗲𝗻𝗰𝗶𝗲𝘀 / 𝗴𝗮𝗶𝗻) | |
| ▸ High | 12 kHz, +/-15 dB |
| ▸ Low | 80 Hz, +/-15 dB |
| Internal effects | 16 |
| Effects send on each channel | yes |
| Pan control on each channel | yes |
| Common mode rejection | -80 dBu |
| S/N ratio | -82 dB |
| Frequency response | 20 Hz - 20 kHz |
| THD | <0.03% @1 kHz |
| MIC input | +60 dBu |
| LINE input | +30 dB |
| Stereo input | 300 mW |
| Bluetooth streaming | yes (playback from any compatible device) |
| LED indicator | two-level |
| Dimensions | 230 x 180 x 55 mm |
Questions frequently asked
How many microphones can be connected to this mixer?
Two balanced MIC/LINE inputs and two microphone preamps are integrated. Phantom power is available for compatible microphones.
Does the Gemini GEM-08USB have built-in effects?
16 internal effects are available, with adjustable effects send on each channel.
What stereo sources can be connected to the mixer?
The mixer features 4 stereo inputs, plus a 2TK input and Bluetooth streaming. A Bluetooth-compatible source can thus stream a backing track. The REC output allows capturing the signal for recording.
Is equalization available on each channel?
Each channel has a 3-band EQ and a pan control. The high and low settings operate at 12 kHz and 80 Hz respectively, with a ±15 dB range.
What are the dimensions of this Gemini mixer?
The unit measures 230 x 180 x 55 mm. A headphone output with dedicated volume and dual-level LED indicators complete the control section.
