Essential Information About the HK Audio Linear SUB 1800 A Active Subwoofer
- 18-inch neodymium driver and built-in 1.2 kW amplification for deep and powerful bass.
- 132 dB peak at 1/2 space, usable bandwidth from 42 Hz (38 Hz at -10 dB) for solid impact.
- Stereo inputs XLR/6.35mm Jack, filtered XLR outputs for satellites, and 2.1 central sub mode.
- 16 mm MDF compact enclosure, M20 pole mount, optional wheels.
A Sub Designed for the Linear 3 Series, Compatible with All HK Audio Sound Systems
Part of the Linear 3 lineage, the L SUB 1800 A adopts the electronics approach of the L SUB 1500 A with an 18-inch driver for more energy. A dedicated switch optimizes alignment when using four subs to thicken the low end. Despite this positioning, it also integrates very well with Linear 5 systems or as reinforcement for a Lucas 2K18 and an Elements BigBase Single kit.
Who Is It For and What For?
Ideal for DJs, event providers, and live bands seeking a robust subwoofer, the L SUB 1800 A excels with electronic music, outdoor shows, or any application requiring clean, deep, and punchy bass, while remaining easy to deploy in 2.1 setups or multi-sub stacks.
Technical specifications
| Battery | No | SPL Max / peak | 132 dB |
| Category | Soundsystem | Frequency response | 42 Hz - 100/120 Hz |
| Type | active subwoofer | SPL max | 130 dB |
| Number of channels | 1 channel | Speaker structure | MDF |
| Amplification | Active amplified | Transport | 2 handles |
| Bluetooth | No | Inputs | 2 x combo XLR/jack |
| Connection | Combo, XLR Link, XLR | Outputs | 2 XLR satellite, link XLR |
| Controls | phase inverter, input gain, cutoff frequency | Color | Black |
| Speaker diameter | 18" | Power output | 1200 W |
| Number of speakers | 1 | Quantity | 1 |
| EQ | No | Weight | 42 kg |
| Cut-off frequency | 100 / 120 Hz | Dimensions (mm) | 510 x 670 x 720 |
| Cutaway | No | ||
Questions frequently asked
Is the HK Audio L Sub 1800 A compatible with Linear 5?
The subwoofer is suitable for speakers from the Linear 3 and Linear 5 series. It can also reinforce a Lucas 2K18 system or an Elements BigBase Single kit.
What connections are available for a 2.1 system?
Two combo XLR/6.35 mm jack inputs can receive a stereo signal. The two filtered XLR outputs feed powered satellites, while an additional XLR Link output is also provided.
What power and low-frequency extension does it offer?
With 1,200 W at 4 ohms and an 18-inch neodymium speaker, this subwoofer covers from 42 Hz up to the crossover frequency selectable at 100 or 120 Hz.
How to use four L Sub 1800 A subwoofers?
A dedicated switch optimizes alignment when using four subwoofers. This function is designed to thicken the low end in a multi-subwoofer setup. The phase inverter also helps to tune with the satellites.
Is the subwoofer suitable for transport and pole mounting?
The 16 mm MDF enclosure includes two handles and weighs 42 kg. An M20 flange allows mounting a pole for satellite speakers, and wheels are available as an option.
