LD Systems U505 BPH 2

A Series Designed to Democratize Wireless Performance on Stage

The U500 series was developed with a simple ambition: to offer a wireless microphone system capable of delivering professional sound, flawless reliability, and solid performance, while remaining accessible. Within the LD Systems range, it positions itself as a solution oriented towards stage and event use, with a design focused on radio stability, ease of use, and faithful transmission, suited to the demands of live performances as well as recurring events.

For Whom and For What Uses?

The U500 series vocal sets are aimed at singers, hosts, speakers, technical teams, and service providers who want to gain freedom of movement without sacrificing quality. Thanks to their advertised range and frequency management, they are suitable for concerts, speeches, corporate events, places of worship, multipurpose rooms, or mobile stages. The series is available in various configurations (handheld transmitter, headset microphone, lavalier microphone, single or dual receivers), making it easy to choose a coherent system depending on the voice, staging, and event format.

• Accurate transmission with no distortion, latency, or alteration

Technical specifications

Category

Complete system

Capsule

dynamic / static

Transmission technology	UHF True Diversity	Microphone type	dynamic or condenser
Switchable RF transmission power	2, 10 or 30 mW	Capsule isolation	against vibration
Range	more than 100 metres in open space	Available sets with	handheld transmitters, headset microphones, lavalier microphones
Channel scanning	automatic	Receivers	single or dual (depending on the set)
Frequency synchronization	" One-Touch " between transmitter and receiver, via infrared	Handheld microphone capsules	interchangeable
Squelch	controlled by pilot tone	Other versions available	for brass instruments, guitar, or with lavalier or headset microphone (depending on the series version)
Display	OLED	U505	584 to 608 MHz (12 systems usable simultaneously)
Displayed information	group, channel, radio frequency, signal strength, battery level	U506	655 to 679 MHz (12 systems usable simultaneously)
User names	can be entered	U508	823 to 832 MHz + 863 to 865 MHz (six systems usable simultaneously)
Transmission battery life	up to 10 hours	U506 UK (Channel 38)	606 to 614 MHz (six systems usable simultaneously)
Transmitter power supply	2 AA batteries	U518	1785 to 1800 MHz (four to six systems usable simultaneously)
