Mackie HM-800

Name: HM-800
Brand: Mackie
SKU: 302532
Price: 249.00 EUR
Availability: InStock
Rating: 5.0 (1 reviews)

249,00 €VAT incl.

3,10 € Ecotax included

Reference price

In stock online

In stock in store

Estimated Shipping Widget will be displayed here!

ID : 302532

EAN : 0663961054101

This item is covered for 3 years

Information

Essential Information About the Headphone Amplifier 8-Channel / 16-Output Headphone Amplifier
• 16 headphone outputs in total, with 2 outputs per channel to share the same mix without compromise
• 8 independent channels: dedicated volume, mono/stereo mode, and input 1/2 selection to tailor monitoring for each musician
• Auxiliary input per channel to add an additional source (click, guide, talkback return, etc.) close to the user
• 7-segment LED VU meters per channel + display on the master to maintain immediate visual control of levels

HM-800

249,00 €VAT incl.

3,10 € Ecotax included

Reference price

A Monitoring Hub Designed for Multi-User Sessions

When multiple performers record simultaneously, the quality of headphone monitoring becomes a decisive factor for comfort and performance. This distribution amplifier follows a simple logic: centralize headphone output, multiply listening points, and maintain clear level control without complicating studio wiring. It naturally fits into advanced home studios, recording control rooms, equipped rehearsal rooms, or live capture setups.

Who Is It For and What Are the Use Cases?

This model is aimed at producers, sound engineers, and musicians who need multiple simultaneous headphone listens with quick individual adjustment. Thanks to the 2 stereo inputs and the input 1/2 selection per channel, you can offer two different main sources (for example, a general mix and a specific mix), then let each user choose the most suitable one. The auxiliary input per channel facilitates adding a local source without disturbing the other mixes.

Technical specifications

Number of channels	16	Direct output	No
Rackable	Yes	Color	Black
Talkback	No	Power supply included	Yes
Category	headphone preamp	Power supply	AC Adapter
Volume per channel	Yes	Weight	3.6 kg
Mono switch	Yes	Dimensions (mm)	224 x 46 x 483
Inputs	2 x 2 x jack, 8 x jack aux in

Questions frequently asked

How many headphones can be connected to the Mackie HM-800?

Each of the 8 channels offers 2 headphone outputs, for a total of 16 outputs. This allows two people to share the same channel with the same volume setting.

Is it possible to send two different headphone mixes?

Two stereo inputs on 6.35 mm jacks are available. Each channel allows selecting input 1 or input 2. This makes it possible to distribute a main mix and a specific mix according to listening needs.

Can each musician adjust their headphone volume?

A volume control is present on each of the 8 channels, with a 7-segment LED level meter display.

Does the HM-800 have individual auxiliary inputs?

Each channel includes an auxiliary input on a jack, totaling 8 Aux inputs. A local source can therefore be added without affecting the other headphone circuits.
