Mipro MA 909

A 2U Chassis Designed to Centralize and Expand a Setup

The Mipro MA 909 is presented as a 2U rack-mountable base, designed to consolidate essential audio management and integration of complementary equipment in one place. Its concept is simple: to offer a metal chassis ready to be installed in a standard rack, with accessible connectivity and dedicated slots to host modules (wireless, source player) as needed. This approach facilitates the setup of a clean, organized, and scalable system, especially appreciated when aiming to limit the number of scattered devices and secure connections.

Who Is the Mipro MA 909 For and What Are Its Uses?

This rackable chassis is aimed at users who need a central audio control point capable of managing one or multiple sources and integrating a wireless microphone solution within the same rack. It is well suited for contexts where a neat and quick-to-use installation is desired: multipurpose rooms, conferences, educational institutions, places of worship, training, light events, or any control room requiring a compact rack. The combo XLR/6.35mm Jack mic input allows quick connection of a wired microphone, while the 6.35mm Jack headphone output simplifies monitoring. The RCA Line in/out connections are convenient for linking consumer devices or compatible external sources.

Features and Integration: Mixer, Connectivity, and Internal Slots

Integrated Audio Section for Direct Handling

The MA 909 includes a mixer and essential connectivity to work without multiplying boxes. The combo mic input (XLR/6.35mm Jack) offers flexibility by accepting different cable types and connection scenarios. The 6.35mm Jack headphone output provides useful monitoring during setup, line testing, or quick checks before use.

RCA Line In/Out: Simple for Connecting Sources

The presence of Line in/out jacks (2 x 2 RCA) facilitates connecting compatible audio sources and sending signals to other equipment. This connectivity is especially appreciated for integrating players, outputs from certain audio devices, or organizing a broadcast/return chain within an installation.

An Architecture Designed to Host Modules (Equipment Not Included)

The MA 909 stands out with its internal slots intended to receive optional equipment (not included). This design allows adapting the rack to the use case: adding a transmitter, wireless receivers, or a source player, while maintaining a compact and coherent unit. The announced slots notably allow integration of 1 x MT 92 transmitter (transmission to speakers equipped with an MRM70 receiver), 2 x MRM 70 receivers (reception of a wireless transmitter like the ACT32), as well as a source player (CD/USB). This modularity is ideal for building a progressive system: starting with the essentials, then expanding as needs evolve, without changing the chassis or reorganizing the entire rack.

Technical specifications
