Requirements According to License Type
EDU: a recent proof (student card, institution certificate, or teaching status) is required at the time of purchase. UPG: proof of ownership of a previous version of VisLM is necessary (serial number/publisher account). CG: proof of ownership of compatible loudness measurement software is requested. A separate DSP AAX version for Avid HDX exists; it uses AAX Hybrid and is not supported by the HDX Hybrid engine.
What NUGEN VisLM 2 Is For
NUGEN VisLM 2 is designed to ensure perceived level consistency across all your deliveries: TV, streaming, podcasts, cinema, radio, or video games. It centralizes key measurements (Momentary, Short-term, Integrated, True Peak) to quickly reach targets, avoid inter-sample distortion, and comply with legislation (CALM Act, R128) as well as internal studio and broadcaster recommendations.
Main Features
Instant Measurement and Compliance
Monitor loudness M/S/I and True Peak in real time, with presets for major broadcast frameworks. "Safe zones" and visual indicators allow hitting targets on the first try, without guesswork.
ReMEM Memory and History
ReMEM technology stores up to 24 hours of data synchronized to your NLE/DAW timecode. Any cut triggers an automatic update of the integrated loudness, avoiding end-to-end re-measurements. Offline AudioSuite analyses can be transferred to the real-time meter for faster-than-real-time measurements.
Granular Control and Readability
True Peak exceedance logging, navigable flags and alerts in the scrolling history, resizable and clear interface for quick decisions, even in live broadcast contexts.
Suitable for Post, Broadcast, and Games
Balance music, dialogue, and effects to deliver consistent masters. Support up to 7.1.2 and PlayStation/Xbox One compatibility facilitate integration into game and VR pipelines.
Technical specifications
| Type | Full software |
| Downloadable | Yes |
| macOS | macOS 10.9; 1 GB RAM. |
| Windows | Windows 7; 1 GB RAM. |
| DSP AAX (optional) | DSP version for Avid HDX using AAX Hybrid; not compatible with HDX Hybrid engine. |
| Compliance | ITU-R BS.1770 (rev. 1 to 4), EBU R128 and R128 S1, ATSC A/85 (CALM Act), ARIB TR-B32, OP-59, AGCOM 219/9/CSP, Portaria 354, DPP (BBC, ITV, C4, C5, S4C). |
| ReMEM | loudness memory locked to timecode (up to 24 hours), saved with the session. |
Questions frequently asked
Is Nugen Audio VisLM 2 compatible with EBU R128 and the CALM Act?
Compliance specifically covers EBU R128 and R128 S1, ATSC A/85 associated with the CALM Act, as well as ITU-R BS.1770 revisions 1 through 4. Presets facilitate monitoring of the main broadcast targets.
Which loudness measurements are displayed in real time?
Momentary, Short-term, and Integrated measurements are available, accompanied by True Peak monitoring. Safety zones and visual indicators notify deviations from the target.
Does the ReMEM memory prevent reanalyzing an entire project?
The ReMEM function records up to 24 hours of loudness data synchronized to timecode. When making cuts in the NLE or DAW, the integrated value updates automatically. The data remains saved with the session.
Does VisLM 2 support immersive 7.1.2 audio?
Support extends up to the 7.1.2 format, for postproduction, gaming, and VR workflows. PlayStation and Xbox One compatibility is also indicated.
What system configuration is required for VisLM 2?
Operation is supported from macOS 10.9 or Windows 7, with 1 GB of RAM. A separate DSP AAX version is offered for Avid HDX with AAX Hybrid, without support from the HDX Hybrid engine.
