Nux NAI-24

A Controlled "Vintage" Spirit Designed for Modern Productions

The NAI-24 embraces a sonic approach that pays tribute to classic studio gear, notably through a FET compression circuit inspired by the type 76 and a Class A transistor input topology. The idea is not to complicate your signal chain but to provide, right from recording, an exploitable color and quick control, with preset modes accessible via digital control. The result: a compact "desktop" interface aimed equally at demanding vocal recording, instrument tracking, or content creation.

An Interface to Record, Produce, and Stream Without Wasting Time

With its 2 inputs and 4 outputs, the NAI-24 positions itself as an ideal solution for home studios, mobile setups, and streaming configurations. The mic inputs allow capturing vocals, acoustic guitar, or line sources, while the HI-Z input facilitates direct recording of guitar and bass. In production, the 4 outputs enable practical scenarios: managing multiple monitor mixes, sending to external systems, or dedicated routing for a musician in an isolation booth.

Content creators will appreciate the loopback feature for cleanly capturing audio from applications (browser, player, video conferencing software) into their DAW, as well as the monitoring settings (soft/hard) to adjust playing feel and responsiveness depending on the session. Finally, the presence of two independently controlled headphone outputs simplifies two-person sessions: artist and engineer, or vocal/instrument duo, without needing an additional headphone amplifier.

Preamps, Compression, and Routing: An Input Chain Designed Like a "Channel Strip"

Generous Gain and Boost Mode

Each input channel relies on Class A transistors with wide dynamic range and offers a maximum gain of 71 dB. The Boost mode adds 8 dB to the overall preamp, useful for gaining level with less sensitive microphones or to keep a comfortable headroom without pushing your chain to the limit.

3 Dedicated Compression Modes (Plus a Boost Mode)

The NAI-24 integrates three compression behaviors quickly accessible to avoid endless tweaking when you need to record fast and well. The Vocal Compression mode favors moderate attack and release for a smoother, more controlled result. The Guitar Compression mode focuses on fast response and calibrated release for guitar and bass, balancing level and stabilizing dynamics. Finally, the Live Streaming Compression mode is the most reactive: it aims to preserve clarity and intelligibility when level variations are frequent during broadcasts.

AKM Conversion and Main Output with Transformers

For conversion, the interface relies on professional AKM AD/DA chips, known for their musicality and precision, preserving detail and depth both in recording and playback. On the output side, the main 1L/2R output benefits from studio-quality audio transformers: besides a warmer signature, they contribute to electrical isolation and reduce interference caused by ground loops. The manufacturer specifies that even with unbalanced connection on 1L/2R, the strength of the balanced output signal is maintained.

Two Speaker Pairs, One Click: A/B and Recording Mode

The NAI-24 offers routing designed for studio realities. In A/B mode, you can connect two pairs of active monitors on 1L/2R and 3L/4R and switch between them via the OUT 3/4 button: ideal for comparing a mix on two different monitors. In recording mode, the OUT 3/4 button adjusts with one click what is sent to channels 3/4, for example to quickly change a headphone mix or musician send during a take.

This logic also facilitates integrating external effects: in recording mode, you can connect effects modules to enrich existing recordings and start a new take without turning your session into a wiring nightmare.

Technical specifications

Category	audio interface	Number of instrument inputs	1
Format	desktop	Number of microphone inputs	2
Phantom power supply	48V, Yes	Number of outputs	4
Provided software	Cubase LE	Color	Blue
Max resolution	32-bits	MIDI	No
Headphone outputs	Yes	Power supply	USB-C
Number of inputs	2	Weight	0.72 kg
Number of analogue inputs	2	Dimensions (mm)	194 x 128 x 67

Maximum resolution	32 bits / 192 kHz	A/B mode	switch listening between outputs 1L/2R and 3L/4R via OUT 3/4
Latency announced	3.17 ms at 192 kHz with 32-sample buffer	Recording mode	adjust sound sent to channels 3/4 via OUT 3/4
Number of analog inputs	2	Included software	Cubase 13 LE
Number of mic inputs	2	Dimensions	194 x 128 x 67 mm
Phantom power	48V
