A DJ cartridge designed for the stage, in the spirit of the VNL series
With the VNL TRIX, Ortofon strengthens its range dedicated to DJs who demand uncompromising performance from their vinyl turntables. This MM cartridge adopts the ergonomics and logic of the VNL series, known for its robustness, while emphasizing two very practical priorities in real-world situations: a high output level to maintain presence and impact in the mix, and a resilience built to withstand long sessions, vibrations, and rapid manipulations. The result is a cartridge oriented towards "field performance": reliable, readable, and designed to stay in place when the booth moves.
For scratch DJs, battle competitors, and residents seeking solid tracking
The VNL TRIX is primarily aimed at scratch DJs, turntablists, and battle competitors who demand a tight groove lock during cuts, dribbles, chirps, crab scratches, and rapid variations. Its behavior in back-cueing and backspins also reassures open-format and resident DJs, especially when equipment is heavily used (platters in continuous use, frequently handled cartridge, booth with strong bass). In mobile contexts, it helps maintain stable playback on setups where vibrations and movement are more prevalent, while keeping a consistent sound from record to record.
Power, stability, and visibility: key assets for vinyl mixing
The spherical diamond is a relevant choice for intensive DJ use: it promotes tolerant, consistent tracking, suited to techniques requiring quick returns to the starting point. The aluminum cantilever and Ortofon's exclusive rubber suspension contribute to mechanical stability, essential to limit skipping during abrupt movements. The quad coil design with OFC wire contributes to a stable sound image and coherent channel separation, useful for maintaining good clarity in a busy mix.
Finally, the fluorescent white stylus provides a very practical advantage in the booth: under UV light, tracking becomes immediate, speeding up cueing and securing entries even when lighting is minimal. Combining a 10 mV output, strong tracking ability, and endurance-oriented construction, the VNL TRIX aims for a rare balance between power, reliability, and ease of use for vinyl DJs.
Technical specifications
| DJing type | Mix, Scratch |
| Category | cell |
| Type | Moving magnet |
| Destination | DJ |
| Diamond tip | spherical |
| Color | Black |
| Quantity | 1 |
| Cartridge weight | 7 g |
| Diamond | spherical |
| Tip radius | R 18 µm |
| Cantilever | aluminum |
| Suspension | Ortofon exclusive rubber |
| Coil system | quad coils |
| Coil wire | OFC |
| Output voltage (1 kHz, 5 cm/s) | 10 mV |
| Channel separation (1 kHz) | 22 dB |
| Frequency response (20 Hz - 20 kHz) | +/-3 dB |
| Dynamic lateral compliance | 12 µm/mN |
| Tracking ability (315 Hz) | 100 µm |
| Recommended tracking force | 4.0 g |
| Recommended load | 47 kOhm |
Questions frequently asked
Is the Ortofon DJ VNL TRIX cartridge suitable for scratching and back-cueing?
This cartridge is designed for mixing and scratching, featuring a spherical stylus with an 18 µm radius adapted for quick returns in the groove. Its tracking ability reaches 100 µm at 315 Hz.
What tracking force should be used with this DJ cartridge?
The recommended tracking force is 4.0 g. This value helps maintain playback during fast manipulations and vibrations.
What output level does the VNL TRIX provide?
The specified output voltage is 10 mV at 1 kHz and 5 cm/s. This level is intended to preserve impact in a vinyl mix.
Is the stylus visible in a dark DJ booth?
The fluorescent white stylus is visible under UV light, which facilitates cueing when the booth is dimly lit.
What are the playback characteristics and channel separation?
The cantilever is made of aluminum and paired with Ortofon's exclusive rubber suspension. The system uses quadruple coils with OFC wire. Channel separation is rated at 22 dB at 1 kHz with a recommended load of 47 kOhm.
