An Ortofon Reference Designed for "Vintage" Playback in the 2M Family
The 2M 78 is part of the Ortofon 2M range, a family of phono cartridges known for its consistency, ease of adjustment, and compatibility with a wide variety of turntables. This model emphasizes playback of 78 rpm records, featuring stylus geometry and tracking parameters designed to prioritize stability, reduce skipping, and provide enjoyable listening even on older pressings.
Who Is It For? DJs, Collectors, Archivists, and Vinyl Enthusiasts
This cartridge is aimed at users who want to utilize a turntable beyond "classic" vinyl: 78 rpm collectors, jazz and historical recording enthusiasts, or profiles focused on digitization/archiving. In DJ contexts, it suits specialized setups and thematic listening where playback reliability and ease of use are paramount.
It will naturally find its place in hi-fi installations as well as on dedicated studio turntables, provided that adjustments (tracking force, angle, and recommended load on the phono preamp side) are carefully made to get the best from your records and preserve the diamond.
Features and Innovations
The 2M 78 is a MM cartridge (moving magnet) rated with an output voltage of 4 mV at 1000 Hz (5 cm/sec), a practical level to achieve good dynamics without excessively boosting the phono preamp gain. Its frequency response from 20 Hz to 20,000 Hz (+3 / -1 dB) ensures coherent reproduction, while its tracking ability at 315 Hz reaches 70 µm (with recommended tracking force), indicating serious tracking on demanding passages.
The spherical diamond (radius R 65 µm) favors robustness and tolerance to imperfections. The recommended tracking force is 1.8 g (18 mN), with an operating range of 1.6 to 2.0 g (16 to 20 mN), to optimize the balance between groove holding, precision, and wear. On the electrical side, the cartridge is designed for a recommended load of 47 kOhm and a load capacitance of 150 to 300 pF, common values that facilitate integration with many phono stages.
Finally, the 2M ecosystem simplifies maintenance: the 2M 78 replacement stylus is announced as interchangeable with the 2M Mono, a tangible advantage for upkeep and evolving your setup.
Technical specifications
| DJing type | Monitoring |
| Category | cell |
| Type | Moving magnet |
| Destination | hifi |
| Diamond tip | spherical |
| Color | Grey |
| Quantity | 1 |
| Diamond | Spherical |
| Stylus tip radius | R 65 µm |
| Cartridge and stylus color | Black/Grey |
| Replacement stylus | 2M 78 (interchangeable with 2M Mono) |
| Diamond lifespan | with proper care, up to 1000 hours without performance degradation |
| Output voltage at 1000 Hz, 5 cm/sec. | 4 mV |
| Frequency response | 20-20,000 Hz (+3 / -1 dB) |
| Tracking ability (315 Hz with recommended tracking force) | 70 µm |
| Compliance, dynamic, lateral | 18 µm/mN |
| Tracking force range | 1.6-2.0 g (16-20 mN) |
| Recommended tracking force | 1.8 g (18 mN) |
| Tracking angle | 20 degrees |
| Internal impedance | 700 Ohm |
| Internal inductance | 350 mH |
| Recommended load resistance | 47 kOhm |
| Recommended load capacitance | 150-300 pF |
| 2MR cartridge weight | 6 g |
| 2M and 2M Verso cartridge weight | 7.2 g |
| Pre-mounted 2M cartridge weight | 16.7 g |
Questions frequently asked
Is the Ortofon 2M 78 Verso cartridge suitable for 78 RPM records?
Its spherical diamond stylus with a radius of R 65 µm is designed for playing 78 RPM records. The tracking capability reaches 70 µm at 315 Hz with the recommended tracking force.
What tracking force should be set for a 2M 78 cartridge?
The recommended tracking force is 1.8 g, or 18 mN. The acceptable adjustment range extends from 1.6 to 2.0 g (16 to 20 mN).
Is an MM phono preamp required for the 2M 78?
This cartridge is a moving magnet (MM) type and outputs 4 mV at 1,000 Hz, measuring 5 cm/s. The phono input should have a load resistance of 47 kOhm and capacitance between 150 and 300 pF.
Is the replacement diamond available and interchangeable?
The replacement stylus designated 2M 78 is interchangeable with the 2M Mono. With proper maintenance, its expected lifespan can reach 1,000 hours without performance degradation.
What type of stylus tip does this cartridge use for 78 RPM records?
The spherical tip with a radius of R 65 µm favors tolerant playback of grooves from older pressings. The specified tracking angle is 20 degrees and the lateral dynamic compliance is 18 µm/mN.
