An EPM Designed in the Soundcraft Spirit: Essentials Without Excess
The Soundcraft EPM 8+2 aligns with the brand's philosophy: prioritizing audio quality and reliability over stacking secondary features. This series benefits from design choices focused on precision, notably the use of tight tolerance components and surface-mount manufacturing, for more consistent and easily repeatable EQ and gain settings. Above all, it features the GB30 mic preamp, originally developed by Graham Blyth, known for its transparency and dynamic reserve.
Intended Uses: Rehearsal, Live, Studio, and Installations
Versatile, the analog mixing console EPM 8+2 is suitable for live mixing (bands, small stages, events) as well as the needs of a home studio or rehearsal room. Its 8 mic/line inputs allow managing a drum kit in a simple setup, multiple vocals, guitars, keyboards, and line sources, while the 2 stereo inputs easily accommodate a keyboard, audio player, or effects returns. It also fits well in places of worship and installations (multi-zone sound reinforcement, multipurpose rooms) thanks to its immediate ergonomics and dedicated outputs (monitor, record, headphones).
Technical specifications
| Type | analog Compact | Rackable | Yes |
| USB stereo recording / playback | No | Headphone output | Jack 6.35, Yes |
| Number of faders | 9 | ||
Questions frequently asked
How many microphones can be connected to the Soundcraft EPM 8+2?
The mixer features 8 mono mic/line inputs equipped with GB30 preamps. Two additional stereo inputs allow connection of keyboards, audio players, or effects returns.
Is 48 V phantom power available?
48 V phantom power is built-in for use with condenser microphones.
Can stage monitors and external effects be managed?
Two configurable auxiliary buses allow feeding stage monitors or external effects processors. Inserts are present on each mono channel as well as on the mix output. An external compressor or equalizer can thus be inserted in the signal path.
Does the equalizer have parametric mids?
The mono channels feature a 3-band EQ with sweepable midrange from 150 Hz to 3.5 kHz, adjustable ±15 dB. The bass is centered at 80 Hz and the treble at 12 kHz.
What are the dimensions and weight of this mixer?
With 330 x 91 x 362 mm and 4.6 kg, this model remains suitable for mobile setups or light permanent installations. The stated power consumption is 35 W.
