Universal Audio Volt 4 Max

Everything you need to know about the Universal Audio Volt 4 Max USB audio interface Studio-ready sound: two Tone Shaping preamps with 60 dB of gain and three harmonic characters-Warmth, Focus and Shine. Compression right at the source: the Max processor offers six presets inspired by studio dynamics processing for vocals, guitars and bass. Expandable setup: 12 inputs / 6 outputs, ADAT or S/PDIF expansion, MIDI, dual headphone output, two pairs of speakers and an integrated USB hub. Modern, secure workflow: color Smart Display, Auto-Gain, anti-clipping protection, loopback, talkback and compatibility with Mac, Windows, iPad and iPhone. The Volt takes things to the next level with a complete studio approach Designed by the team behind the renowned Apollo interfaces, the Universal Audio Volt 4 Max takes the desktop audio interface concept far beyond simple audio conversion. In a compact format, it brings together preamps with analog coloration, real-time dynamics processing, extensive connectivity and control tools usually associated with more ambitious studio setups. This Max version stands out with its color Smart Display, switch for two pairs of monitors, talkback microphone, USB hub and intelligent level management functions. It meets the needs of creators who want to keep a desktop setup that is quick to use without giving up a professional workflow. An audio interface for recording, producing, streaming and mixing without compromise The Volt 4 Max is aimed at singer-songwriters, beatmakers, guitarists, singers, podcasters and content creators who want to capture their sources with more character right from the recording stage. Its two mic/line inputs and two front-panel Hi-Z instrument inputs make it easy to connect vocals, guitar, bass, synthesizer or drum machine. Thanks to

Technical specifications

Compatibility	PC, Mac, iPad	Number of outputs	6
Sampling frequency	192 kHz	Color	Grey
Max resolution	32-bits	Nominal mode power consumption (Wh)	6 W
Headphone outputs	Yes

Type	desktop USB audio interface	Microphone input dynamic range, A-weighted	119 dB
Simultaneous inputs / outputs	12 inputs / 6 outputs	Microphone input total harmonic distortion + noise	-110 dB, or 0.0003 percent at 1 kHz and -1 dBFS
Audio conversion	32-bit / 192 kHz	Maximum microphone input level	14 dBu
Supported sample rates	44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz	Microphone input impedance	2 k ohms
DAW compatibility	major DAWs, including Ableton Live, FL Studio, GarageBand, Logic Pro and Pro Tools	Phantom power	+48 V, independently switchable per channel
Construction	robust and elegant chassis	XLR polarity	pin 2 positive
Number of microphone preamps	2	Line inputs 1-2	2 line inputs on 6.35 mm balanced TRS or unbalanced TS jack connectors
Available gain	60 dB, digitally controlled	Line input 1-2 frequency response	20 Hz - 20 kHz, plus or minus 0.05 dB
Tone Shaping modes	Warmth, Focus and Shine	Line input 1-2 dynamic range, A-weighted	119 dB
Number of Tone and Max combinations	more than 18	Line input 1-2 total harmonic distortion + noise	-108 dB, or 0.0004 percent at 1 kHz and -1 dBFS
Instrument inputs 1-2	2 front-panel Hi-Z inputs	Maximum line input 1-2 level	22 dBu
Instrument input frequency response	20 Hz - 20 kHz, plus or minus 0.02 dB	Line input 1-2 impedance	10 k ohms
Instrument input dynamic range, A-weighted	116 dB	Line inputs 3-4	2 inputs on 6.35 mm balanced TRS or unbalanced TS jack connectors
Instrument input total harmonic distortion + noise	-108 dB, or 0.0004 percent at 1 kHz and -1 dBFS	Line input 3-4 frequency response	20 Hz - 20 kHz, plus or minus 0.05 dB
Maximum instrument input level	13 dBu	Line input 3-4 dynamic range, A-weighted	119 dB
Instrument input impedance	1 M ohm	Line input 3-4 total harmonic distortion + noise	-108 dB, or 0.0004 percent at 1 kHz and -1 dBFS
Instrument connectors	6.35 mm unbalanced TS jack	Maximum line input 3-4 level	22 dBu
Microphone inputs 1-2	2 XLR / jack combo inputs	Line input 3-4 impedance	10 k ohms
Microphone input frequency response	20 Hz - 20 kHz, plus or minus 0.08 dB
