Essential Information About the ADJ Startec "Rayzer" Projector
Essential Information About the ADJ Startec "Rayzer" Projector
- 2-in-1 Effect combining red/green/blue lasers and powerful SMD LED Wash for compact yet highly impactful shows.
- Ready to Play: music and automatic show modes, plus 26-channel DMX control for fine programming.
- Intense Colors thanks to 126 RGB SMD5050 (3-in-1) LEDs, pre-programmed color rings, and built-in strobe.
- Mobile Format: lightweight housing with suspension yoke, 4-button LCD display, and DMX/IEC daisy-chaining for quick setups.
Manufacturer Information
ADJ
https://www.adj.com
info@adj.com
------------------------
Safety manager:
ADJ Supply Europe B.V.
Email: info@adj.eu
Address:
A Compact Effect That Energizes Stages, Dancefloors, and Events
The "Rayzer" blends aerial laser beams and a colorful light wash to instantly fill a dance floor, small stage, or event space. Used with a smoke or fog machine, the laser patterns gain volume and cut through the air, while the RGB Wash envelops the setting with a uniform tint or striking rainbow effects. Ideal for intimate clubs, bars, ice rinks, private parties, weddings, or fixed installations requiring maximum impact in minimal space.
For Mobile DJs, Lighting Technicians, and Entertainment Venues
Designed for versatility, this projector targets DJs and hosts seeking a lightweight, quick-to-deploy setup, event professionals looking for a "wow" effect without overloading the lighting desk, as well as operators of small clubs, bars, or leisure centers. Lighting technicians will appreciate the precise DMX control to integrate the Rayzer into synchronized shows, while individuals and associations will benefit from its internal programs for turnkey events.
Technical specifications
| Spotlight type | Hybrid | Color | Multicolor |
| LEDs | 126 RGB SMD5050 (3-in-1) at 0.2 W | Operation | standalone or in Master/Slave configuration |
| Lasers | red, blue and green, geometric patterns | Strobe effect | yes |
| Color rings | pre-programmed, rainbow effects | Housing | lightweight plastic with suspension yoke |
| Wash effect | yes | Safety eyelet | on the rear panel |
| Number of DMX channels | 26 | DMX daisy-chaining | via 3-pin cable |
| Protocol | DMX-512 | Power connections | IEC input/output, serial power linking |
| Dimming | 0â100% | Power consumption | 53 W max. |
| Display | 4-button LCD on the rear panel | Auto-ranging power supply | 100 V to 240 V, 50/60 Hz |
| Laser safety lock | key-operated, on the rear panel, laser unlock/shutdown | Dimensions (L x W x H) | 210 x 217 x 235 mm |
| Several operating modes | music mode, Show mode or DMX control | Weight | 2.2 kg |
| Built-in Shows | combination of color Wash and laser patterns | ||
You will also like
Algam Lighting
Phebus 2
Power Lighting
LIGHTBOX 90S
Chauvet DJ
Swarm 5 FX ILS
Power Lighting
STELLA
Power Lighting
Turnbeam
Chauvet DJ
Abyss 2
ADJ
REVO 4 IR
ADJ
H2O IR
Questions frequently asked
Can the ADJ Rayzer be controlled via DMX?
DMX-512 control on 26 channels allows adjusting colors, dimmer from 0 to 100%, strobe, rings, and laser sequences. DMX connection is done through a 3-pin XLR.
What is the power and composition of the RGB wash?
The wash is based on 126 SMD5050 RGB 3-in-1 LEDs at 0.2 W each. Pre-programmed color fades and rainbow rings are available.
Is a smoke machine required with this laser effect?
Using a smoke or fog machine makes airborne laser beams more visible and volumetric. The unit remains usable without smoke, with its RGB wash and integrated programs.
Which standalone modes are available?
Built-in Show programs and music mode allow use without a DMX controller. Settings are made via the 4-button LCD display.
Is the fixture easy to install on a structure?
With dimensions of 210 x 217 x 235 mm and a weight of 2.2 kg, the unit mounts via its mounting bracket. A IEC in/out allows power linking of multiple units, while a safety cable eyelet is provided. A key lock enables activating or deactivating the laser.
