Essential Information About the Allen & Heath Xone:43 Mixer
- Reference analog sound with VCA faders and wide dynamic range for precise and warm mixes.
- 4 channels + 1 mic/aux input and dual RCA inputs per channel to connect turntables, CD/media players, and line sources.
- Legendary Xone VCF filter with high-pass, low-pass, and band-pass modes, adjustable resonance for creative transitions.
- Professional connectivity with balanced XLR outputs, booth output, effects send/return, and dual headphone jacks.
Manufacturer Information
Allen&Heath
https://www.allen-heath.com
------------------------
Safety manager:
Algam SAS
Email: contact@algam.net
Address:
At the Heart of Allen & Heath's Club Range
The big sister of the Xone:23, the Xone:43 continues Allen & Heath's "club" DNA with a 100% analog architecture, robust build, and ergonomics designed by and for DJs. Designed in the UK, it carries forward the sonic choices that have made the Xone series renowned in booths worldwide.
For Which DJs and Contexts?
From passionate amateurs to club professionals, the Xone:43 is aimed at those seeking a reliable, intuitive, and musical mixer. Perfect for fixed installations (bars, clubs), mobile DJs, as a backup for DVS setups, or home studios, it offers clear controls, effective cueing, and universal compatibility with phono and line sources.
Technical specifications
| Number of faders | 4 | Number of mic preamps | 1 |
| Number of channels | 4 | Mic inputs | XLR |
| Bluetooth | No | Line inputs | 4 x line-level RCA |
| EQ | 3 channels | Inputs (other) | FX return : RCA, 4 x Rca phono |
| Motorised faders | No | Main outputs | 2 x XLR |
| Filters | Low pass | Outputs (other) | headphone 6,35 mm stereo jack, headphone 3,5 mm stereo jack, Record RCA, FX send RCA, monitor Rca |
| Rackable | Yes | Color | Black |
| Category | console club | Display | Meter |
| Fader travel | 60 mm | Weight | 5.1 kg |
| Crossfader | Penny & Giles | Dimensions (mm) | 320 x 110 x 370 |
| 4-channel switching | Phono / Line | Effects send | RCA |
| Phono inputs | 4 x RCA phono | Headphone outputs | 6.35 mm stereo jack and 3.5 mm stereo minijack (front panel) |
| Inputs per channel | dual RCA with adjustable levels | VCF filter system | low-pass, band-pass, high-pass with resonance control |
| Effects return | RCA | Per-channel effect loop | send and return with Dry/Wet adjustment |
| Booth/monitor output | RCA | Fader technology | VCA |
| Other outputs | 2 x RCA | Button backlighting | by color |
| Recording output | RCA | Weight (kg) | 5.10 |
You will also like
RELOOP DJ
RMX 60 Digital
OMNITRONIC DJ
TRM-422M - 4-Channel Rotary Mixer
Headliner
R4
RELOOP DJ
RMX-44 BT
LD Systems
ZONE 624 - MIXER 4 ZONES RACKABLE 3 U
Union Audio
ELARA.6 Rotary Fader Pack for all ELARA.6 Mixers
Union Audio
ELARA.6 Line Fader Pack for all ELARA.6 Mixers
RELOOP DJ
RMX-95
Questions frequently asked
Does the Xone 43 accept vinyl turntables and line-level players?
All 4 channels feature switchable RCA phono/line inputs, totaling 4 RCA phono inputs and 4 RCA line inputs. Levels can be adjusted individually per channel.
What filter is built into this DJ mixer?
The VCF system offers low-pass, band-pass, and high-pass modes with resonance control. It allows processing of channel signals to create transitions and build-ups.
Is the crossfader suitable for scratching?
A Penny & Giles crossfader with three cut curve options is installed. It is replaceable and compatible with an Innofader, enabling adaptation of the response to various playing techniques.
What audio outputs are available on the Allen & Heath Xone 43?
The main output uses 2 balanced XLR connectors, while the booth/monitor output is RCA. An RCA recording output and RCA effects send/return are also present.
Can headphones be connected via jack and minijack?
Two headphone outputs are located on the front panel: a 6.35 mm stereo jack and a 3.5 mm stereo minijack.
