Charvel Pro-Mod Plus Dinky DK24 HH FR EB Ebo Crimson Eclipse
Estimated Shipping Widget will be displayed here!
- This item is covered for 3 years
Couldn't load pickup availability
Information
Information
Manufacturer Information
Charvel
https://www.fender.com
------------------------
Safety manager:
Fender (EDC) B.V.
Email: contactemea@fender.com
Address:
Technical specifications
| Electronics: microphone configuration | HH | Body | Linden |
| Category | ST | Bridge / tailpiece | Floyd |
| Left handed | No | Electronics | Passive |
| Strings | Steel | Color | Purple |
| Nbr of strings | 6 | Finishing | Glossy |
| Fingerboard | Ebony | Hardware | Black |
| Nbrs of frets | 24 | ||
| Shape | Dinky | Whammy bar | Floyd Rose 1500 Series Locking |
| Body material | basswood | Tuners | Charvel die-cast |
| Body finishing | gloss lacquer | Hardware finishing | Black |
| Neck construction | bolt-on, with graphite reinforcement | Control knobs | Speed Knob |
| Neck material | caramelized maple | Pickup covers | Black |
| Neck finishing | natural satin | Neck plate | none, sculpted 4-bolt heel |
| Headstock | Licensed Fender Stratocaster style | Original strings | nickel-plated steel, gauge .009-.042 |
| Key | ebony | Pickup configuration | HH |
| Radius | 12" to 16" / 304.8 to 406.4 mm | Bridge pickup | Seymour Duncan Nazgul |
| Key markers | 4 mm pearloid dots | Neck pickup | Seymour Duncan Sentient |
| Side markers | Luminlay | Controls | volume with 500K low-friction potentiometer, no-load tone |
| Number of frets | 24 | Selector switch | 5 positions |
| Fret type | jumbo stainless steel | Position 1 | bridge pickup |
| Scale length | 25.5" / 648 mm | Position 2 | outer coils of both pickups |
| Nut | Floyd Rose 1500 locking | Position 3 | bridge and neck pickups |
| Nut material | Floyd Rose 1500 locking | Position 4 | inner coils of both pickups |
| Nut width | 1.6875" / 42.86 mm | Position 5 | neck pickup |
| Truss rod | dual action with adjustment wheel at heel | Auxiliary switching | 2-position mini-switch, down all series, up all parallel |
| Bridge | recessed Floyd Rose 1500 Series double locking | ||
