The DCI (DriveCore Install) Range: A "Installation" Approach from Crown
Designed for fixed sound reinforcement applications, the DCI (DriveCore Install) series emphasizes reliability, channel density, and routing flexibility in multi-distribution environments. The guiding principle is clear: to deliver the design quality associated with Class AB amplifiers while benefiting from the thermal and energy efficiency advantages of a Class D architecture. Depending on site requirements, DCIs are available in DCI ANALOG version (analog inputs) or DCI NETWORK version, designed for managed and supervised installed systems.
Who Is This Amplifier For and In Which Applications Does It Excel?
With its 8 channels, this DCI is aimed at integrators, venue managers, and technicians who need to power multiple zones from a single chassis: room speakers, space monitors, reception areas, corridors, ancillary rooms, or segmented distribution systems. The 70 V outputs (and, depending on version, 100 V) facilitate distributed line architectures typical of long-distance installations, while the high and low impedance selection per channel allows topology adaptation for each zone. In practice, this results in clearer wiring, consistent levels, and easier daily operation.
Questions frequently asked
What power does the Crown Audio DCI8300n deliver per channel?
The amplifier delivers 8 x 300 W at 4 ohms, 8 ohms, and 70 V line. At 2 ohms, the power is 8 x 150 W.
Can the DCI8300n power multiple sound zones?
Its 8 channels allow powering separate zones from a single chassis, such as a room, a lobby, or ancillary spaces. High and low impedance selection is done per channel.
Can 70 V line speakers be used with this amplifier?
A 70 V output of 300 W is available on each of the 8 channels, suitable for distributed sound systems.
Can the channels be bridged?
Channel bridging by pairs is provided when a zone requires more power. This function integrates with the multi-zone routing logic of the DCI series.
What are the amplifier's dimensions and weight?
The chassis measures 47.5 x 8.75 x 35.63 cm and weighs 10.7 kg. The DriveCore architecture reduces the number of internal components. A universal power supply and an advanced cooling system are integrated for fixed installations.
