Eminence DELTA-12A
Estimated Shipping Widget will be displayed here!
Essential Information About the Delta-12A Bass/Midrange Speaker
Essential Information About the Delta-12A Bass/Midrange Speaker
- High Efficiency: rated sensitivity of 98.3 dB to achieve a high output level without pushing the amplifier too hard.
- 12-inch (31 cm) versatile format, ideal for bass/low-midrange in PA speakers and stage monitors.
- 400 W at 8 ohms: a speaker designed to handle and remain stable at sustained volume levels.
- Robust construction: ferrite magnet and steel frame, built for touring and intensive rigging.
Manufacturer Information
Eminence
https://www.eminence.com
info@eminence.com
------------------------
Safety manager:
MSC Distribution
Email: infos@msc-distribution.com
Address:
Technical specifications
| Cabinet impedance (Ω) | 8 Ω | Magnet | Ferrite |
| Speaker diameter | 12" | Chassis | steel |
| Sensitivity | 98,3 | Coil diameter | 64 mm |
| Frequency response - start | 54 Hz | Power output | 400 W |
| Frequency response - end | 5 kHz | Weight | 5.17 kg |
| Category | loudspeaker | ||
| Type | bass/midrange | Frequency response | 54 Hz to 5 kHz |
| Power | 400 W | Frame | steel |
| Nominal impedance | 8 ohms | Voice coil diameter | 64 mm |
You will also like
Turbosound
TS-18SW700/8A
B&C Speakers
MMD3BTN8M
B&C Speakers
MMD3ATN8M
B&C Speakers
Recone Kit for 18PZB100 8 Ohms
B&C Speakers
Recone Kit for 18PS76 8 Ohms
B&C Speakers
10HPL64 16 Ohms
Eminence
BETA-12A-2
Eminence
Midrange speaker 16,5cm 100W 8 ohms
Questions frequently asked
Is the Delta-12A suitable for a 12-inch PA speaker cabinet?
This model is designed for PA applications, with a power rating of 400 W at 8 ohms. Its sensitivity of 98.3 dB promotes a high acoustic level at equivalent amplification power.
What is the frequency response of this 12-inch speaker?
The specified response ranges from 54 Hz to 5 kHz. This range covers the bass and low-mid frequencies, with a usable rise towards a crossover region with a compression driver or tweeter.
Can it be installed in a bass-reflex enclosure?
A bass-reflex loading is among the intended applications for this speaker. The internal volume of the enclosure, the port tuning, and the crossover influence the final result.
What amplification is recommended for a 400 W, 8-ohm speaker?
The nominal impedance of 8 ohms allows for either a single or paired setup depending on the amplifier architecture. The rated power is 400 W.
Is the Delta-12A frame sturdy enough for PA use?
The frame is made of steel and the magnet is ferrite. The 64 mm voice coil contributes to power handling during sustained operation.
