FBT Install CANTO 8CA B

A Canto Series Speaker Designed for Modern Installations

The FBT Install CANTO 8CA is part of the Canto series, a range focused on installation that emphasizes easy integration, consistent coverage, and daily reliability. Its compact size, black finish, and carefully crafted Made in Italy design make it a natural choice for public venues, event spaces, and setups where clean sound is expected without taking up much space.

Ideal Uses for the CANTO 8CA

Thanks to its 2-way active design, the CANTO 8CA is perfectly suited for nearfield sound reinforcement and intelligible music playback: bars and restaurants, shops, multipurpose rooms, classrooms, corporate spaces, places of worship, museums, as well as voice reinforcement and background music during events. Its Line / Mic selector facilitates source adaptation, while the Link output allows chaining a second speaker to cover a larger area.

DSP, Sound Dispersion, and Connectivity: A Simple and Effective Approach

Class D Amplification and Controlled Dynamics

The Class D amplification delivers a comfortable power of 200 + 100W rms (and 400 + 200W max ) to maintain headroom even at high levels. With a continuous max SPL of 120dB and a peak max SPL of 125dB, the CANTO 8CA can provide energetic sound coverage while preserving clarity, especially for vocals and spoken content.

8-inch Speaker + 1-inch Driver: Balance and Precision

The low/mid section is based on an Ø8-inch (210mm) speaker with a Ø2-inch (51mm) voice coil, while the high frequencies are handled by a tweeter with a Ø1-inch (25.4mm) driver and a Ø1.4-inch (35.5mm) voice coil. This combination allows balanced reproduction, with a frequency response from 50Hz to 20kHz, suitable for both background music and announcements or speech.

80deg x 80deg Coverage and Quick Adjustments

The 80deg x 80deg dispersion promotes even coverage, useful to limit overly loud or quiet zones in the room. Regarding adjustments, everything is designed to focus on essentials: volume potentiometer, DSP with 4 presets to tailor the curve according to use, HPF filter to optimize the low end when used with a subwoofer or to control bass in installations, and a Line / Mic level selector to match the input to the signal.

Integration: 35mm Mount and Mounting Options

For setup, the speaker features a Ø35mm socket for a speaker stand, convenient for gigs or temporary installations. For a more discreet and adjustable integration, an adjustable mounting bracket (WM-68) is available sold separately, ideal for optimizing the dispersion angle in a room.

Technical specifications

Bluetooth

No

Model	FBT Install CANTO 8CA Black	Frequency response	50Hz - 20kHz
Type	2-way active speaker	Max continuous SPL	120dB
Series	Canto	Max peak SPL	125dB
Manufacturing	Italy	DSP switch	4 presets
Color	Black	Level switch	Line / Mic
Amplification type	Class D	Input	3-pin female XLR
Max power LF + HF	400 + 200W	Link	3-pin male XLR
RMS power LF + HF	200 + 100W	Enclosure material	molded polypropylene
Speaker	Ø8 inches (210mm), voice coil Ø2 inches (51mm)	Socket	Ø35mm for speaker stand
Tweeter	driver Ø1 inch (25.4mm), voice coil Ø1.4 inches (35.5mm)	Adjustable mounting bracket	WM-68 (sold separately)
Dispersion H x V	80deg x 80deg
