An Acoustasonic in Jazzmaster format: Fender innovation for the stage
The American Acoustasonic Jazzmaster follows the line of Fender hybrid instruments designed for modern guitarists: a hollow body inspired by the brand's iconic shapes, combined with advanced electronics that allow blending and transforming textures. Made in Corona, California, it holds a premium position in the Acoustasonic series, featuring a larger format that favors breadth and presence.
Who is it for, and what styles?
This electro-acoustic guitar is especially aimed at intermediate to expert guitarists who want a single instrument capable of covering multiple roles: acoustic accompaniment, punchy rhythms, more aggressive humbucker-style tones, and hybrid sound layers. Ideal for pop, rock, indie, soul, worship, film music, or any studio and stage situation where flexibility is key without sacrificing playing comfort.
The sound
The combination of a solid Sitka spruce top and a mahogany back and sides delivers an acoustic character that is both precise and warm, with good projection and well-grounded lows, enhanced by the large Jazzmaster-inspired body. The ebony fingerboard adds attack and definition, useful for complex chord playing as well as single-note passages.
On the electronics side, the guitar uses three complementary sources: the piezo under the saddle for acoustic snap and dynamics, the internal body sensor for "body" feel and air, and the Shawbucker magnetic pickup for a denser, more aggressive, electric-typed response. The 5-position selector and "Blend/Mod" potentiometer allow navigating between distinct voices and gradual blends to achieve particularly inspiring hybrid tones.
Recommended compatible accessories
To maintain the original feel and balance, plan for a replacement set of Fender Dura-Tone 860CL phosphor bronze coated strings (.011-.052) identical to the factory-installed set.
Technical specifications
| Electronics: microphone configuration | Hybrid | Nbrs of frets | 22 |
| Category | Asymmetric | Body | Mahogany |
| Left handed | No | Bridge / tailpiece | Fixed |
| Strings | Steel | Electronics | Active |
| Nbr of strings | 6 | Color | Blue |
| Top | Spruce | Finishing | Satin |
| Fingerboard | Ebony | Hardware | Chromed |
| Type | hollow body | Fret size | narrow tall |
| Body shape | Modified Jazzmaster | Radius | 12" / 305 mm |
| Wood | mahogany | Fingerboard radius type | modern |
| Back | mahogany | Scale length | 25.5" / 648 mm |
| Sides | mahogany | Nut | Graph Tech TUSQ |
| Body finish | satin matte polyester | Nut material | Graph Tech TUSQ |
| Bracing | cross bracing | Nut width | 1.6875" / 42.86 mm |
| Rosette | 2-ring black/white/black | Truss rod | Bi-Flex |
| Bridge | modern and asymmetrical | Truss rod nut | 1/8" American Series |
| Pickguard | none | Truss rod wrench | 1/8" hex (Allen) |
| Orientation | right-handed | Hardware finish | chrome |
| Neck material | mahogany | Tuners | Fender Standard Cast/Sealed Staggered |
| Neck wood type | mahogany | Special electronics | 3-pickup configuration (piezo under saddle, internal body sensor, acoustic magnetic Shawbucker) |
| Neck shape | modern deep C | Controls | main volume, "Blend" knob, 5-way switch |
| Neck profile type | C shape | Case / gig bag | included, Deluxe 1225 gig bag |
| Neck finish | satin urethane | Power supply (not included) | micro USB connector |
| Fingerboard inlay | white dot | Power supply (not included), input | 100-240 V, 50/60 Hz, 0.3 A |
| Number of frets | 22 | Power supply (not included), output | 5 V DC, 1000 mA |
Questions frequently asked
What sounds can the Fender Jazzmaster Modified American Acoustasonic EB Ocean Turquoise produce?
The hybrid electronics combine a piezo under the saddle, an internal body sensor, and a Shawbucker magnetic pickup. The 5-way selector provides access to different tones, while the Blend/Mod control allows for progressive mixing. The solid Sitka spruce top and mahogany body support a warm and defined acoustic response.
Is the Shawbucker pickup suitable for electric sounds?
The magnetic Shawbucker offers a dense and more aggressive response, electric-typical, complementing the acoustic sources.
What are the neck dimensions and playability comfort?
The mahogany neck features a modern deep C profile, with a 648 mm scale length and a 42.86 mm nut width. The ebony fingerboard has a modern 305 mm radius and 22 narrow, tall frets. Its satin urethane finish promotes smooth playability.
Is this Acoustasonic suitable for stage and studio use?
This model is suitable for stage and studio environments requiring acoustic, hybrid, or more assertive textures. Its three pickup sources allow switching from the piezo character to the magnetic pickup's density, with the addition of the body sensor.
What replacement strings should be used on this guitar?
The original setup uses Fender Dura-Tone 860CL phosphor bronze coated strings, gauge .011-.052. This set maintains the intended feel and balance of the instrument.
