Powerful Shows, Indoors and Outdoors
Designed for demanding environments, the Laserworld PL-20000RGB IP65 delivers spectacular performance on stage, in clubs, theaters, or at high-end corporate events and weddings. Thanks to its IP65 protection, it also excels outdoors for architectural mapping, festivals, facades, and permanent installations in amusement parks, bars, and restaurants. Its wide projection angle and high scanning speed guarantee strong visual impact even on large surfaces.
Who Is It For?
This Class 4 show laser is intended for production companies, lighting technicians, designers and integrators, venue operators, clubs, and professional DJs seeking a reliable, powerful, and versatile solution. It is also suitable for equipment fleets aiming to standardize their network control (Art-Net/DMX/LAN) while benefiting from a smooth workflow with ShowNET and the included ShowEditor software.
Features and Innovations
At the heart of the PL-20000RGB IP65, the ShowNET motherboard unlocks all modern control options: traditional ILDA, professional DMX or Art-Net (each in two modes), as well as LAN control via computer thanks to the integrated DAC. The ILDA streaming receiver facilitates integration into existing networks. In standalone or master-slave mode, it sequences ready-to-use effects, perfect for permanent installations or shows triggered without a console. Regarding output, its red 638 nm, green 520 nm, and blue 450 nm diodes totaling 20000 mW produce intense and homogeneous colors. The 6.5 mm beam at 0.9 mrad maintains sharpness over long distances, while the 35 kpps scanning speed at 8 deg ensures smooth and stable drawings for text, logos, or complex graphics. With 120 basic patterns (layers, tunnels, fences, waves, etc.), you have an immediate effects library, expandable via your creations in the full-featured ShowEditor software provided. The unit is delivered in a waterproof flight case with power cable, manual, and interlock key for secure access.
Technical specifications
| Source type | RGB laser diodes |
| Laser class | 4 |
| Red | 638 nm / 6000 mW |
| Green | 520 nm / 8000 mW |
| Blue | 450 nm / 8000 mW |
| Total power | 20000 mW |
| Beam | 6.5 mm / 0.9 mrad |
| Maximum projection angle | 50 deg |
| Scanning speed | 35 kpps at 8 deg |
| Basic patterns | 120 (layers, tunnels, fences, waves, etc.) |
| Motherboard | Integrated ShowNET |
| Control options | ILDA, professional DMX (two modes), professional Art-Net (two modes), standalone operation, master-slave |
| Network | LAN for computer control (integrated DAC) |
| Receiver | ILDA streaming |
| Included software | ShowEditor (full version) |
| Protection rating | IP65 |
| Included accessories | waterproof flight case, power cable, manual, interlock key |
| Dimensions | 427 x 280 x 220 mm |
| Weight | 26 kg |
| Input voltage | 85 V - 250 V AC, 50/60 Hz |
| Power consumption | 750 W |
Questions frequently asked
Can the Laserworld PL-20.000 RGB IP65 be used outdoors?
The IP65 rating allows outdoor use for facades, festivals, amusement parks, and fixed installations. A waterproof flight case is provided for transport.
What is the power and range of the beam?
The total power reaches 20,000 mW, divided into 6,000 mW red at 638 nm, 8,000 mW green at 520 nm, and 8,000 mW blue at 450 nm. The 6.5 mm beam has a divergence of 0.9 mrad, to maintain a fine projection over long distances.
Which control modes are available?
The built-in ShowNET card supports ILDA, professional DMX, and Art-Net, with two modes for each of the last two protocols. Computer LAN control is provided by the integrated DAC. Standalone and master-slave modes are also available.
Can this laser project logos and text?
With a scan speed of 35 kpps at 8°, it is designed for stable tracing of text, logos, and graphics. Its 120 patterns include tunnels, layers, fences, and waves, while full ShowEditor software is included to create content.
What precautions and accessories are provided?
Class 4 laser classification, this device comes with an interlock key for secure access. The package also includes a power cable, a manual, and a waterproof flight case.
