Microtech Gefell UMT70S
Estimated Shipping Widget will be displayed here!
- This item is covered for 3 years
What you need to know
What you need to know
- Directional Versatility: three selectable modes (omni, cardioid, figure-8) via a ring under the grille to adapt to all studio and broadcast configurations.
- Double Diaphragm Capsule with a brass backplate and gold-plated diaphragms, for exceptional clarity and low coloration.
- Transformerless Electronics offering exemplary transient response, improved RF immunity, and extended dynamic range.
- Proximity Control with a high-pass filter and a -10 dB pad for very loud close-miked sources.
Manufacturer Information
Microtech Gefell
https://www.microtechgefell.de
info@microtechgefell.de
------------------------
Safety manager:
Microtech Gefell GmbH
Email: info@microtechgefell.de
Address:
A Classic Capsule Heritage, Modernized
The UMT 70 S continues the DNA of great side-address studio microphones while adopting modern electronics. The output transformer is replaced by an active balancing stage, ensuring precise lows, detailed highs, and better rejection of RF interference. Result: lowered self-noise, increased dynamic headroom, and daily reliability.
For Demanding Vocals and Instruments
Designed for vocal and instrumental soloists, radio, television, and any critical recording, the UMT 70 S delivers faithful and present reproduction. Whether for voice-over or singing, strings, winds, guitars, or piano, it integrates easily thanks to its adaptable directivity and controlled proximity behavior.
Key Features and Sonic Advantages
The directivity selector located under the head instantly switches between omni, cardioid, and figure-8. The omnidirectional pattern remains perfectly flat in the lows, with a slight boost of about 2 dB around 10.5 kHz to open up the high end. The cardioid and figure-8 modes offer a "presence bump" of up to 4 dB around 7 kHz, combined with a subtle low-frequency roll-off: the signature that creates the sense of "presence" and separation in the mix.
The side-address design (sensitivity axis perpendicular to the body) facilitates placement near bulky sources. The high-pass filter limits proximity effect in cardioid and figure-8 modes, while the -10 dB pad secures against high SPLs. Power is supplied via 48 V phantom power according to DIN 45596 and IEC 268-15 standards, through a standard 3-pin XLR connector.
Technical specifications
| Frequency response - start | 20 Hz | Directivity | omnidirectional, cardioid, bidirectional |
| Frequency response - end | 20 kHz | Connection | XLR |
| Category | studio microphone | Color | Grey |
| Selectable polar patterns | omnidirectional, cardioid, figure-8 | PO 70 pop filter (black) | Ref. 600018 |
| Omni | flat response in the lows, slight 2 dB boost at 10.5 kHz | MH 75 microphone stand (black) | Ref. 202306 |
| Cardioid and figure-8 | presence bump up to 4 dB around 7 kHz, slight low-frequency attenuation | MKV 9 clip (black) | Ref. 600001 |
| Extended dynamic range | reduced self-noise and better headroom before saturation | EA 21 elastic suspension (satin nickel) | Ref. 202318 |
| Finish options | satin nickel or matte black | EA 21 elastic suspension (matte black) | Ref. 202319 |
| Satin nickel | Ref. 211130 | Modified elastic suspension AT 8410 a (anthracite) | Ref. 600004 |
| Matte black | Ref. 211131 | N 200 power supply | Ref. 202101 |
| W 76 windscreen (anthracite) | Ref. 202407 | C 70 connection cable | Ref. 202212 |
You will also like
Neumann
TLM 49
AKG
C414 XLS Stereo
Austrian Audio
OC818 Black Dual Set Plus
Austrian Audio
OC818 Silver Dual Set Go
AKG
C414 XLII Stereo
Warm Audio
WA-87 R2 TS
Austrian Audio
OC818 Dual Set Plus
Warm Audio
WA-CX24
Questions frequently asked
What polar patterns does the Microtech Gefell UMT70S offer?
The three selectable polar patterns are omnidirectional, cardioid, and figure-8, via a switch located under the capsule.
What power supply is required for this studio microphone?
The required power is 48 V phantom power, compliant with DIN 45596 and IEC 268-15 standards. Connection is made via a 3-pin XLR socket.
Does the low-cut filter help with close vocal recordings?
Thanks to the high-pass filter, the proximity effect can be reduced in cardioid and figure-8 modes. The -10 dB pad also helps protect recordings at high sound pressure levels.
What is the cardioid frequency response signature on the UMT70S?
In cardioid mode, a presence boost of up to 4 dB around 7 kHz is combined with a slight roll-off in the low frequencies. This response enhances vocal and instrument separation in a mix.
Which accessories are listed for this microphone?
For mounting, a satin nickel EA 21 shock mount is listed under the number 202318. A W 76 anthracite windscreen is also indicated under the reference 202407. The C 70 connection cable has the reference 202212.
