An Analog "Reissue" Delay: The Charm of Bucket-Brigade Updated
The Nux Analog-Delay Reissue is designed for those seeking the typical feel of vintage analog delays: repeats that are less "surgical" than on a digital delay, with a slight softness on the attack and a natural warmth that blends into the playing. Its Bucket-Brigade circuit and BBD chip (type 3205/3305 depending on the series) aim precisely for this classic-inspired sound that has marked pedalboards from rock to funk and pop, especially from the late 70s through the 80s.
Within the range, this pedal positions itself as a simple, straightforward analog delay focused on the essentials: quickly achieving a musical echo, without menus, presets, or feature overload. An ideal approach to concentrate on touch and rhythmic placement.
Who Is the Nux Analog-Delay Reissue For, and Which Styles Does It Excel In?
This pedal suits both beginner guitarists looking for an easy-to-set first delay and seasoned musicians seeking an authentic analog sound to complement their pedalboard. Its immediate usability is perfect for rehearsals, live shows (quick adjustments between songs), and studio work when you want a lively echo texture that doesn't mask the dry signal.
Regarding styles, it excels on a slap-back for rockabilly and blues, short and groovy delays for pop/funk, or longer, more present times for rock and lead playing. Paired with overdrive or distortion, it adds a very "old school" depth: repeats stack more smoothly, helping maintain a clear sound without harshness.
Technical specifications
| Effects | Delay, Effects | EQ | No |
| Technology | Analog | Settings | blend, repeats, time |
| Format | Pedal | Use | guitar |
| Inputs | Jack | Color | Pink |
| Outputs | Jack | Power supply included | No |
| True bypass | Yes | Power supply | 9V battery, DC 9 V |
| Display | Led | Weight | 230 g |
| Switch | On/Off | Dimensions (mm) | 121 x 77 x 48 |
| Number of effects | 1 | ||
Questions frequently asked
What kind of delay sound does the Nux Analog-Delay Reissue produce?
The Bucket-Brigade circuit equipped with a BBD 3305 chip generates warm and slightly softened repeats. This warm texture blends into the dry signal without producing a sharp echo effect.
Can a slap-back effect be dialed in with this pedal?
The Time control allows for short delay settings suitable for slap-back effects typical of rockabilly and blues. Repeats adjusts the number of echoes, while Blend sets their level within the overall signal.
What power supply is required for the Nux Analog-Delay Reissue?
The power input accepts a 9 V battery or a 9 V DC source delivering a minimum of 300 mA. No power adapter is included.
Does the pedal preserve the tone once bypassed?
True bypass minimizes signal coloration when the effect is off. An LED indicates the On/Off switch status on the pedalboard.
What are the connections and dimensions of this pedal?
The input and output use jack connectors. The size measures 121 x 77 x 48 mm with a weight of 230 g.
