Palmer PWT 06 IEC

A Power Supply Designed for Modern Pedalboards

On a pedalboard, the multiplication of pedals and cables can turn your setup into a genuine "interference antenna." The Palmer PWT 06 IEC belongs to the brand's new generation of isolated power supplies: each isolated output is designed to provide stable, ultra-low noise power distribution to preserve playing dynamics, attack clarity, and silence between notes.

Its pedalboard-oriented format and IEC mains connector make it a practical solution for guitarists and bassists who want clean, reliable wiring, ready for both stage and studio.

Who Is the Palmer PWT 06 IEC For?

This pedal power supply is aimed at musicians who use multiple effects and want to eliminate hum and unwanted noise often associated with shared power supplies. It is especially suitable for pedalboards combining analog pedals (overdrive, fuzz, compression) and digital pedals (delay, reverb, compact multi-effects), where power quality becomes crucial.

It is also relevant if you are looking for an "all-in-one" solution capable of managing, in addition to pedals, the charging or powering of USB equipment useful in rehearsals and on the go.

Key Features: Isolation, Power, and Versatility

Isolated Outputs: Cleaner Signal, Pedal by Pedal

The PWT 06 IEC offers 6 isolated 9V DC center-negative outputs. Individual isolation helps limit interactions between pedals and contributes to quieter operation, especially when combining sensitive effects (vintage fuzz, wah, high-gain overdrives) with more demanding digital pedals.

Variable Voltage 6-18 V: Adapt the Behavior of Certain Pedals

Thanks to its variable voltage output from 6 to 18 V, you can adjust the power supply to explore different playing sensations. At lower voltage, some pedals may offer different compression and a more "spongy" texture. At higher voltage (if the pedal accepts it), you often gain headroom and precision, useful for overdrives and boosts.

18 W USB-C and USB-A: The Ally of Hybrid Setups

The PWT 06 IEC integrates USB-C and USB-A ports delivering up to 18 W. Ideal for charging a mobile device or powering certain USB accessories in a modern setup without adding an extra charger to the power strip.

Non-Isolated 9V DC 2000mA Output: Extension and Specific Needs

A non-isolated 9V DC 2000mA output is also available, convenient for powering a compatible additional module (for example a PWT04) or equipment requiring more current, while keeping the isolated outputs free for the most sensitive pedals.

Built-in Protection and Supplied Cables

Each output benefits from short circuit and overload protection, an essential feature for a pedalboard subjected to frequent plugging and unplugging. Palmer also provides the DC cables and the power cable for quick setup.

Technical specifications

Current	2 A	Category	Multiple power supply
Voltage	9 V	Number of outputs	6

Power Supply	universal with IEC mains inlet	Variable-Voltage Output	1 outlet, 6 - 18 V
USB Power Sockets	USB C and USB A, 18 W	Non-Isolated DC Output	1 outlet, 9V DC, 2000mA, compatible with a PWT04, for example
Power Cable	included	DC Cable	included
Isolated DC Outputs	6 individual outlets, center-negative, 9V DC	Protection for Each Outlet	against short circuits and overloads
