Essential Information About the Shure SLXD4Q+ Digital Wireless Receiver
- 4 channels in 1U: a quad rack format that saves space and simplifies multi-mic systems.
- 24-bit digital audio: transparent reproduction with a stated dynamic range of 118 dB.
- Robust and intelligent RF: digital predictive switching diversity, frequency scanning, and fast IR synchronization.
- Designed to scale: audio summation (4, 3, 2, or 1) and RF cascading to expand up to 8 channels with two units, no additional accessories required.
SLX-D: a "pro" approach to wireless, designed for multi-channel configurations
The digital wireless system SLX-D is designed to offer a solid balance between ease of use, audio quality, and RF reliability, while remaining particularly comfortable as the number of channels increases. In this logic, the SLXD4Q+ positions itself as the heart of a multi-mic setup: a quad receiver in a 1U rack format that reduces footprint, limits the number of power supplies, and streamlines cabling, whether in fixed installation or live performance.
This "all-in-one" approach is ideal for standardizing a fleet of receivers, saving setup time, and maintaining a clear overview of the system: 4 channels managed within a single unit, with an architecture ready to grow as needs evolve.
What is the SLXD4Q+ made for?
The SLXD4Q+ is aimed at environments where stable and clean capture is required without complicating things: theaters, places of worship, conferences, events, community centers, education, corporate control rooms, or providers who need to quickly deploy a coherent set of channels.
Its 1U quad format is particularly relevant for mobile racks, touring flight cases, and any control rooms where space is limited. Paired with compatible transmitters, it suits both vocals (handheld, headset, lavalier microphones) and certain instrument inputs, depending on the microphone or capsule used.
Technical specifications
| Frequency response | 20 Hz - 20 kHz | Max. number of simultaneous systems | 40 |
| Category | wireless microphone receiver | Transmission | digital |
| Directivity | / | Weight | 1.75 kg |
| Capsule | / | Dimensions (mm) | 42 x 393 x 152 |
Questions frequently asked
Can the Shure SLXD4Q+E-G65 handle four wireless microphones?
This digital quad receiver manages 4 channels in a 1U rack chassis measuring 42 x 393 x 152 mm. It must be paired with compatible transmitters to establish the wireless links.
How to connect this quad receiver to a mixing console?
Four XLR outputs are available to send each channel separately. Audio summing also allows adapting the 4 channels to 3, 2, or 1 output depending on the inputs available on the mixer.
Is it possible to set up an 8-channel Shure SLX-D system with two receivers?
The RF cascade function allows linking two units to create an 8-channel system without additional accessories.
What is the audio quality of the SLX-D quad receiver?
The 24-bit digital transmission offers a dynamic range of 118 dB. The specified frequency response ranges from 20 Hz to 20 kHz, depending on the microphone used.
Is the receiver compatible with Wireless Workbench?
Two local Ethernet connections enable network integration. Compatibility with Shure Wireless Workbench facilitates supervision of multiple links. Synchronization between receiver and transmitter is done by scanning followed by infrared.
