Historical Context and Positioning in the Range
Since the 1960s, the Vox AC30 has established itself as one of the major sonic signatures of rock guitar, with its unique blend of brightness, lively mids, and progressive saturation. The Vox AC30S1 continues this legacy by focusing on the most iconic DNA of the model: the Top Boost channel. While some AC30s offer multiple inputs, more channels, or more complex configurations, the AC30S1 adopts a modern and streamlined approach: a single channel, the right controls, and current features (reverb, effects loop) to capture the AC30 spirit in a format that's easier to transport and use daily.
Who This Amp Is For
The Vox AC30S1 is aimed at guitarists who want a true all-tube combo with a distinctly British character, without getting lost in multi-channel architectures. It suits both intermediate musicians seeking a "definitive" amp to progress with, and experienced guitarists needing a reference sound in the studio, rehearsals, or on small to medium stages. Style-wise, it excels in rock, indie, pop, alternative, blues, and anything requiring crisp cleans, precise arpeggios, and saturation that builds with pick attack and guitar volume.
Technical specifications
| Category | Guitar combo |
| Technology | Tubes |
| Input | effect loop jack, instrument jack |
| Output | Cabinet, Effect loop jack |
| External cabinet output | Yes |
| Effects loop | Yes |
| Reverb | Yes |
| Footswitch input | Yes |
| Amp tubes | 4 x EL84 |
| Cabinet | Straight |
| Cabinet impedance (Ω) | 16 Ω |
| Speaker | Half-open |
| Attenuator | No |
| Category | Amplifier |
| Number of effects | 1 |
| Number of channels | 1 |
| Speaker diameter | 12" |
| Number of speakers | 1 |
| EQ | 2 channels |
| Color | Brown |
| Power output | 30 W |
| Weight | 24.5 kg |
| Dimensions (mm) | 658 x 265 x 550 |
Questions frequently asked
Is the Vox AC30 S1 suitable for rehearsals and small venues?
Its 30 W RMS and 12-inch Celestion VX12 speaker provide sufficient projection for rehearsals and small to medium-sized stages. The combo weighs 24.5 kg and measures 658 x 265 x 550 mm.
What sound does the Top Boost channel offer?
The single Top Boost channel delivers bright, clear tones with pronounced mids. Increasing the gain drives the saturation from crunch to a harmonic-rich overdrive, powered by 4 EL84 tubes.
Can delay and reverb be connected in the effects loop?
A Send/Return effects loop on jack allows insertion of external delays, reverbs, and modulations after the preamp distortion. A digital reverb is also built into the combo.
What impedance is recommended for an external speaker cabinet with this amp?
The external speaker output is designed for 16 ohms impedance. The internal 12-inch Celestion VX12 speaker is also rated at 16 ohms.
Is there a power attenuator?
No attenuator is built-in. The controls are based on a single channel, with Gain, Volume, Bass, and Treble knobs.
