The essentials to know about the Allen & Heath ZED-10 analog top
The essentials to know about the Allen & Heath ZED-10 analog top
- Pro-quality audio inherited from Allen & Heath’s expertise, with preamps inspired by the MixWizard series.
- Compact 10-channel format designed for mobile use, small stages, rental companies, and classrooms.
- 2 high-impedance inputs (on jack connectors) for plugging a guitar directly in, with an “amp-like” character thanks to a Class A FET circuit.
- Configurable stereo USB audio interface and comprehensive monitoring section for easy recording and monitor management.
Manufacturer Information
Allen&Heath
https://www.allen-heath.com
------------------------
Safety manager:
Algam SAS
Email: contact@algam.net
Address:
A Compact ZED That Carries the DNA of Allen & Heath Consoles
Within the Allen & Heath range, the ZED-10 stands out as a compact analogue console designed with practicality firmly in mind, without compromising on the build quality and “live” approach inspired by the brand’s models. Designed for musicians and technicians who need a reliable tool, it showcases a design shaped by decades of professional mixing experience, all housed in a chassis that is easy to transport. Its distinctive design, notably with its red side wings, clearly highlights its place in the ZED family.What Are the ZED-10’s Most Suitable Applications?
The ZED-10 is primarily aimed at small groups, lightweight live setups, educational institutions and rental applications where a mixer is easy to use, robust and flexible enough to handle a variety of sources. It is also very well suited to home studios and stereo recording thanks to its configurable USB input/output, which is convenient for capturing a live mix or making a quick recording without multiplying the number of external boxes.Another key point for musicians: the ZED-10 naturally accommodates instruments such as guitar, as well as stereo sources (CD/MP3 player, keyboard, playback). This makes it possible to manage a complete setup (vocals, instrument, backing tracks) with a compact-format console, while retaining genuine routing options for the stage and monitoring.
Technical specifications
| Insert | Yes | Recording | USB |
| Number of faders | 0 | Number of auxiliary sends | 2 |
| Number of channels | 10 | Mic inputs | 4 x XLR |
| Phantom power supply | Yes | Line inputs | 2 x stereo jack, 4 x jack, playback 2 x stereo jack |
| Bluetooth | No | Inputs (other) | USB |
| EQ | 3-band with semi-parametric mid and 2-band per channel | Main outputs | 2 x XLR |
| Motorised faders | No | Outputs (other) | USB, Aux jack, headphone 6,35 mm stereo jack, FX jack, Record RCA |
| Filters | Low cut | Color | Grey |
| PFL/AFL mode | Yes | Display | LED |
| Rackable | Yes | Weight | 3.3 kg |
| Category | analog mixer | Dimensions (mm) | 336 x 275 x 50 |
| Number of mic preamps | 4 | ||
| Mic/line inputs | 4 (including 2 Class A high-impedance inputs) | Monitoring | comprehensive |
| Jack connectors | Neutrik 6.35 mm jack | PFL indicator | backlit |
| Stereo sources | 2, compatible with an MP3 player | Level control | on each input |
| DI switching | possible | Built-in effects | 16 |
| Monitor output | stereo | VU meters | 12 segments |
| Recording outputs | separate 2-track | Dimensions | 336 x 275 x 50/95 mm |
| Auxiliaries | 2 | Weight (kg) | 3.30 |
| Pan control | yes | ||
You will also like
Yamaha
MG10XU
Yamaha
MG10xuf
Allen & Heath
ZEDI-10FX
Behringer
Xenyx QX2222USB
Behringer
X2222 USB
Mackie
PROFX10V3
Midas
DM16
Behringer
Xenyx QX1832USB
Customer reviews
Based on 3 reviews
- 5 stars, 3 reviews
- 4 stars, 0 reviews
- 3 stars, 0 reviews
- 2 stars, 0 reviews
- 1 star, 0 reviews
The review form didn't open. Please try again.
-
I have been using the ZED 10 table for several years.
It is compact and very practical for Podcast or Music recordings.
The USB connection is automatically detected on Windows 10 and Mac.
Possibility of recording via USB and the choice to listen to the record track or Monitor or Phone.
This makes it easy to juggle and save only the tracks you want.
Really comprehensive, and lots of features.
I regret that I did not use the FX model to add voice effects while singing.
Frankly a good product!Automatically translated
-
I have been using the ZED 10 table for several years.
It is compact and very practical for Podcast or Music recordings.
The USB connection is automatically detected on Windows 10 and Mac.
Possibility of recording via USB and the choice to listen to the record track or Monitor or Phone.
This makes it easy to juggle and save only the tracks you want.
Really comprehensive, and lots of features.
I regret that I did not use the FX model to add voice effects while singing.
Frankly a good product!Automatically translated
-
Perfectly satisfied with the product and the order
Automatically translated
No reviews match this filter.
Reviews can't be loaded right now. Please try again.
Automatically translated
Questions frequently asked
Does the Allen & Heath ZED-10 allow recording to a computer via USB?
The configurable USB audio input/output enables capturing a stereo recording and integrating the mixer into a computer setup. The source assigned to the USB can be selected according to routing needs.
Can a guitar be connected directly to this mixer?
Two jack inputs on channels 3 and 4 feature high impedance with Class A FET circuitry, allowing a guitar to be plugged in directly without a DI box. Two rear switches add a 26 dB boost for instruments with low output levels.
How many microphones can be connected?
Four XLR mic inputs with preamps are available, providing phantom power. The four mic/line channels include a high-pass filter and EQ suitable for source processing.
What monitor mixes and external effects can the mixer manage?
Two auxiliary sends allow for stage monitors or external effects processors. A stereo insert jack complements the options for integrating external processing. The headphone output and monitor output have source selection.
Is the ZED-10 suitable for small gigs and rehearsals?
This model offers 10 channels in a compact format of 336 x 275 x 50/95 mm and weighs 3.3 kg. The main outputs on 2 XLRs, stereo inputs, and two auxiliaries meet the needs of a lightweight setup with vocals, instruments, and playback.
