At the Crossroads of Hi-Fi and Professional DJing at Audio-Technica
Born from Audio-Technica's expertise, a reference in phono cartridges for over 50 years, the AT-LP140XP is aimed at professionals who prioritize musicality and precision. Positioned within the DJ range as a robust and streamlined turntable, it emphasizes mechanical quality and playback fidelity rather than gimmicky features.
For Selectors, Audiophile Bars, and Demanding Home DJs
Ideal for clubs and audiophile bars, reggae, jazz, soul, or disco selectors, and home DJs focused on "selection and seamless mixing," this turntable excels in Hi-Fi playback and fixed installations. Its chassis and highly damped feet promote detailed listening at sustained volume levels. However, it is not designed for intensive scratching performances.
Features and Innovations
Fully manual, the AT-LP140XP combines a high-stability direct drive motor with a molded aluminum platter that is damped and anti-resonant. The S-shaped tonearm offers comprehensive adjustments (VTA, tracking force, anti-skating) and comes ready to play with the DJ cartridge AT-XP3 (0.6 mil conical stylus) pre-mounted on the AT-HS6 headshell. The tempo fader provides three pitch ranges (+/-8%, +/-16%, +/-24%) with quartz lock and forward/reverse playback. Designed for the phono inputs of your mixers and amplifiers, it delivers a 5.5 mV phono signal via a detachable dual RCA cable. Additional features include removable stylus illumination, a stroboscopic platter, a protective dust cover, and complete accessories for immediate setup. Available in black (AT-LP140XP-BK) or silver (AT-LP140XP-SV).
Technical specifications
| Digital conversion | No | Dimension | 12" |
| Bluetooth | No | Outputs | Rca |
| Drive | direct | Color | Black |
| Drive mechanism | direct drive | Power consumption | 11 W |
| Type | 3 speeds, fully manual | Weight | 10.0 kg (without dust cover) |
| Motor | high torque | Dimensions | 24.6 x 45.6 x 55.1 cm |
| Speeds | 33 1/3 RPM, 45 RPM, 78 RPM | Model | AT-XP3 |
| Pitch variation | +/-8%, +/-16%, or +/-24% | Output voltage | 5.5 mV (1.0 kHz, 5 cm/s) |
| Platter | aluminum | Vertical tracking force | 2.0 to 4.0 g (standard 3.0 g) |
| Starting torque | 2.2 kgf.cm | Stylus type | conical |
| Speed fluctuation | less than 0.2% WRMS (33 RPM) | Stylus size | 0.6 mil |
| Signal-to-noise ratio | greater than 50 dB | Recommended load impedance | 47,000 ohms |
| Output level | 5.5 mV nominal at 1 kHz, 5 cm/s | Included | detachable RCA cable, power cable, 45 RPM adapter, counterweight, felt mat, removable dust cover, AT-HS6 headshell |
| Power requirements | 220 V AC, 50 Hz | ||
Questions frequently asked
Is the Audio-Technica AT-LP140XP-SR suitable for DJ mixing?
The high-torque direct drive motor of 2.2 kgf.cm and selectable pitch fader at ±8%, ±16%, or ±24% meet the needs for mixing and beatmatching. Forward/reverse playback and quartz lock are also available. This turntable is not intended for heavy scratching.
Which cartridge is supplied with this turntable?
The DJ cartridge AT-XP3 is pre-mounted on an AT-HS6 headshell. Its 0.6 mil conical stylus operates with a recommended tracking force of 3.0 g, adjustable from 2.0 to 4.0 g.
Can this turntable be connected to an amplifier or mixer?
The phono output delivers 5.5 mV via a detachable dual RCA cable provided. A phono input with a recommended load impedance of 47,000 ohms is required.
Does the turntable play 33, 45, and 78 RPM records?
Speeds of 33 1/3, 45, and 78 RPM are supported, with a 45 RPM adapter included.
What accessories are included with the AT-LP140XP-SR?
Included are a detachable RCA cable, a power cable, a slipmat, and a removable dust cover. The set also includes a counterweight, a 45 RPM adapter, and the AT-HS6 headshell. A removable stylus illumination light is also provided.
