Electrovoice ELX200-15P-W White
Estimated Shipping Widget will be displayed here!
- This item is covered for 3 years
What you need to know
What you need to know
- Powerful and Controlled Sound Reinforcement : Class D amplification delivering 600W RMS / 1200W peak and up to 132dB SPL max to cover demanding performances.
- Versatile 15-inch Format : solid bass and effective projection thanks to the EVS-15M 15" woofer and 1" DH-1L titanium tweeter.
- Modern DSP and Control : QuickSmartDSP (presets, 3-band EQ, user memories) + LCD screen for quick adjustments on site.
- Complete Connectivity + Bluetooth : RCA and combo XLR/6.35mm TRS jack inputs, XLR output, Bluetooth player, and control via the EV QuickSmart Mobile app.
Manufacturer Information
Electrovoice
https://www.electrovoice.com
------------------------
Safety manager:
MSC Distribution
Email: infos@msc-distribution.com
Address:
ELX200: An Electro-Voice Solution Designed for Stage and Events
With the ELX200 series, Electro-Voice targets portable sound reinforcement that combines efficiency, reliability, and ease of use. The ELX200-15P-W embodies this philosophy in an active 15" format, designed to deliver high sound pressure levels and balanced reproduction while remaining easy to transport and quick to set up. The white finish makes it a particularly suitable choice for performances where aesthetics matter as much as performance (events, places of worship, discreet installations).
A 15" Active Speaker for DJs, Bands, Conferences, and Elegant Installations
The Electro-Voice ELX200-15P-W is aimed at users who want a speaker capable of providing a compact front of house, stage monitoring, or occasional reinforcement without multiplying components. Its frequency response (up to 16kHz at -3dB) promotes good clarity of vocals and instruments, while the 15" driver provides the necessary foundation for amplified music. In pairs, it forms an effective stereo system for mobile DJs, small to medium-sized bands, conferences, or sound reinforcement in commercial and event spaces.
QuickSmart DSP, SST Waveguide, and Ergonomics: Efficiency in Daily Use
QuickSmartDSP: Clear, Fast, and Memorizable Settings
The QuickSmartDSP processing simplifies setup: selection of 4 presets, 3-band equalization, 5 user presets to recall your settings, and essential control functions (input level, main volume, limiter monitoring). The LCD screen allows visualization and adjustment of parameters without wasting time, a real advantage when adapting to a room in a few minutes.
Wireless Control: Bluetooth and Mobile App
The Bluetooth player provides a convenient solution for background music or playlists without extra cables. To go further, the EV QuickSmart Mobile app allows remote configuration, control, and monitoring of the speaker: useful during installation, soundchecks, or when the speakers are mounted on stands and less accessible.
Even Projection: SST Waveguide and 90 x 60 Dispersion
The patented SST (Signal Synchronized Transducers) waveguide is designed to promote coherent dispersion and good intelligibility. With a 90deg x 60deg dispersion, the ELX200-15P-W effectively covers a listening area, helping to limit "hot spots" and maintain a more consistent sound depending on the audience's position.
Technical specifications
| Bluetooth | Yes | ||
| Model | Electro-Voice ELX200-15P-W | QuickSmartDSP | 4 presets, 3-band equalizer, 5 user presets, limiter monitoring, input level control, master volume control |
| Speaker type | active | Display | LCD |
| Amplification | Class D | Inputs | 2 RCA |
| Max SPL | 132dB | Grille | 18 AWG steel with powder coating |
| Frequency response (-3 dB) | 55Hz // 16kHz | Number of handles | 3 |
| Frequency response (-10 dB) | 48Hz // 19kHz | Pole cup diameter | 35mm |
| Tweeter | 1" (25.4mm) DH-1L Titanium | Rigging points | 3 x M10 |
| Patented waveguide | SST (Signal Synchronized Transducers) | Power supply | 100 / 240 V~, 50 / 60 Hz, 1.2 ~ 0.6A |
| Crossover | 1.6 kHz | Dimensions | 710 x 423 x 384mm |
| Dispersion (H x V) | 90deg x 60deg | Weight | 18.9kg |
| EV QuickSmart Mobile App | remote configuration, control and monitoring of the speaker | ||
You will also like
QSC Pro audio
K12.2
RCF
Art 915-A
RCF
Art 915-AX
QSC Pro audio
K8.2
RCF
Art 912-AX
Mackie
SMK SRM212-V-CLASS
QSC Pro audio
K10.2
HK Audio
L3 112 FA (UNIT)
Questions frequently asked
Is the Electrovoice ELX200-15P-W suitable for a mobile DJ or a band?
This 15-inch active speaker delivers up to 132 dB SPL and is suitable for a stereo setup in small to medium-sized venues. Its frequency response from 55 Hz to 16 kHz at -3 dB provides a solid foundation for amplified music.
Can music be streamed via Bluetooth on this speaker?
The built-in Bluetooth player allows the streaming of playlists or background music without additional cables.
What DSP settings are available on the ELX200-15P-W?
The QuickSmartDSP offers 4 presets, a 3-band equalizer, and 5 user memories. The LCD screen provides access to input level, main volume, and limiter monitoring. The EV QuickSmart Mobile app also enables remote control and monitoring.
What is the dispersion of the 15-inch white Electro-Voice speaker?
The SST waveguide ensures a dispersion of 90° x 60°. This coverage promotes even sound distribution within the listening area.
Can the speaker be flown (suspended)?
Three M10 rigging points are provided for installation. The 18 AWG powder-coated steel grille and white finish are suited for event contexts or discreet installations.
