- Complete control center: main volume management, source selection, switching between two pairs of monitors, mono/mute/dim functions.
- Built-in USB audio interface with 24-bit / 96 kHz resolution to directly record your voice, instruments, and line sources into your software.
- Two Onyx microphone preamps with shared phantom power, designed for clean and detailed recordings in home studios as well as vocal booths.
- Optimized studio workflow: talkback via built-in talkback microphone and 2 front-panel headphone outputs with independent volume controls.
Manufacturer Information
Mackie
https://www.mackie.com
------------------------
Safety manager:
Algam SAS
Email: contact@algam.net
Address:
The "Studio" Version: The Big Knob Designed for Recording, Not Just Listening
The Big Knob Studio carries the DNA of the Big Knob monitor controller, appreciated for its immediate usability and large central knob, adding a true "audio interface" dimension. This "Studio" version positions itself as a compact hub to organize a workstation: control monitoring, quickly switch between multiple sources and monitors, and capture recordings at 24-bit / 96 kHz quality without cluttering the desk with multiple boxes.Who Is It For, and What Studio Uses?
The Mackie Big Knob Studio targets producers, beatmakers, podcasters, and musicians who want a reliable monitor controller while keeping a simple and efficient USB audio interface for recording. It is perfectly suited for setups with two pairs of speakers (nearfield and secondary listening), overdub sessions, and situations where you need to quickly switch from one source to another (USB return, line inputs, 2-track) without adjusting software settings.Technical specifications
| Category | audio interface | Number of analogue inputs | 6 |
| Digital outputs | USB | Number of digital inputs | 2 |
| Digital input type | USB | Number of instrument inputs | 4 |
| Format | desktop | Number of microphone inputs | 2 |
| Phantom power supply | Yes | Number of outputs | 7 |
| Compatibility | Mac OS 10.8 or higher, Microsoft Windows 7 SP1 oder höher | Number of digital outputs | 2 |
| Sampling frequency | 192 kHz | Color | Black |
| Interfacing | USB 2.0 | Power supply | 100 - 240 V AC - 50/60 Hz |
| Max resolution | 24-bits | Weight | 1.8 kg |
| Headphone outputs | Yes | Dimensions (mm) | 160 x 248 x 80 |
| Number of inputs | 10 | ||
| Audio interface | USB | Input for mobile source | 3.5 mm jack on the front panel |
| Resolution | 24-bit / 96 kHz | Monitor outputs | 2 stereo outputs (A and B) |
| Source selector for recording | 2-track / input 1/2 | Output trim control | on the front panel |
| Mic/line inputs | 2 combo XLR/6.35 mm TRS inputs with Onyx preamps | Headphone volume control | independent for each output |
| Gain controls | independent | Common headphone monitoring selector | cue/2-track |
| Phantom power | common | Main volume control | large knob (" Big Knob ") |
| Monitoring selector | stereo | Source selector button | 1/2, 3/4 and USB |
| Stereo inputs | 2 (3/4 and 2-Track) | Output selector button | A/B |
| Connectivity | 2 x 6.35 mm TRS jacks (balanced and unbalanced) | Talkback microphone | built-in with volume control |
| Level selector | +4/-10 dB | Buttons | mono, mute and dim |
| Input trim control | on the front panel (3/4 only) | Dimensions | 160 x 248 x 80 mm |
You will also like
Palmer
Monicon XL
Palmer
MONICON L G2 G
Palmer
Monicon L G2
Heritage Audio
Baby Ram Module Monitoring
Art
SCC Studio Control Center
Presonus
Monitor Station V2
Radial
MC3
Mackie
Bigknob Studio +
Customer reviews
Based on 2 reviews
- 5 stars, 2 reviews
- 4 stars, 0 reviews
- 3 stars, 0 reviews
- 2 stars, 0 reviews
- 1 star, 0 reviews
The review form didn't open. Please try again.
-
A product of exceptional quality
Automatically translated
-
A product of exceptional quality.
Automatically translated
No reviews match this filter.
Reviews can't be loaded right now. Please try again.
Automatically translated
Questions frequently asked
Does the Mackie Big Knob Studio allow connecting two pairs of speakers?
The A/B output selector enables switching between two pairs of monitors. The front panel trim controls adjust their levels for consistent listening comparisons.
Can a microphone and a guitar be recorded with this interface?
Two combo XLR/1/4" inputs with Onyx preamps allow connection of microphones or instruments. Phantom power is available for microphones requiring it.
What is the USB recording quality?
Recording is offered at 24-bit / 96 kHz resolution via USB 2.0.
Do the two headphone outputs have separate volume controls?
Each front panel headphone output has its own volume control. The common selector switches between cue and 2-track listening.
Is talkback built into the controller?
An integrated talkback microphone allows communication with musicians during takes. Direct monitoring is provided for overdubbing without latency. A front panel mini-jack input accepts a reference source such as a smartphone.
