A Power Supply Designed for Modern Pedalboards
The MACRO POWER S8 falls into the category of multi-output power supplies intended to centralize power for a pedalboard and simplify wiring. With its 9V outputs at different current levels and a selectable voltage output, it aims for a clear and scalable setup, whether you use "classic" pedals or models requiring more headroom.
Who Is It For and What Are Its Uses?
This pedal power supply is aimed at guitarists and bassists who want to power multiple effects while limiting individual adapters, whether in rehearsal, home studio, or on stage. It is particularly suitable for mixed pedalboards (overdrive, modulation, delay, reverb) where current needs can vary from one pedal to another, and where a variable voltage output can be handy for specific formats.
Key Features: Versatility, Safety, and Easy Integration
9V Outputs and Multi-Voltage Output
The S8 offers 3 outputs at 9V delivering 200 mA each, as well as 4 outputs at 9V sharing 400 mA combined. It adds a selectable voltage output at 9/12/15/18V capable of providing up to 300 mA, useful for adapting power to certain pedals or higher headroom requirements.
Protection and Mains Compatibility
To secure your effects chain, the power supply includes surge protection. A 220/110V switch also allows adaptation to the mains depending on your usage context, convenient if you travel with your gear or if your setup requires it.
Metal Enclosure and Included Accessories
The metal enclosure promotes durability and stability on pedalboards. The supplied cables and Velcro strip enable quick setup for a clean installation and easy access to connections.
Technical specifications
| Current | 0.3 A |
| Voltage | 9 V |
| Category | Multiple power supply |
| Number of outputs | 8 |
| Type | pedal power supply |
| 3 outputs at 9V | 200 mA each |
| 4 outputs at 9V | 400 mA combined |
| 1 selectable voltage output | 9/12/15/18V, 300 mA |
| Mains power switch | 220/110V |
| Protection | surge protection |
| Enclosure | metal |
| Supplied with | cables and Velcro strip |
| Dimensions | 165 x 83 x 52 mm |
| Weight | 1.12 kg |
Questions frequently asked
How many pedals can the Mooer Macro Power S8 power?
This power supply has 8 outputs: 3 outputs at 9 V with 200 mA each, 4 outputs at 9 V totaling 400 mA, and one selectable output.
What voltage does the adjustable output provide?
The dedicated output can be set to 9, 12, 15, or 18 V and delivers up to 300 mA. It allows powering pedals that require a voltage different from the standard 9 V.
Are the 4 outputs at 9 V with 400 mA independent?
The 4 outputs at 9 V share a total reserve of 400 mA. The combined consumption of pedals connected to these outputs must not exceed 400 mA. Three other outputs provide 200 mA each at 9 V individually.
Is the power supply suitable for both 110 V and 220 V mains?
A 220/110 V switch is integrated to adapt the power supply to the mains voltage used.
What accessories are included and what are the dimensions?
Power cables and a velcro strap are provided for pedalboard installation. The metal housing measures 165 x 83 x 52 mm. Its weight is 1.12 kg.
