An Installation Speaker Designed for Daily Playback
This speaker fits within the logic of installed sound systems: reliable, repeatable, and easy-to-deploy playback, whether in retail, reception, hospitality, public spaces, multipurpose rooms, or circulation areas. Its wall-mounted format and durability-focused construction make it a relevant solution for projects requiring both visual discretion and long-term reliability, without relying on built-in electronics.
The absence of DSP, EQ, mixer, or connectivity (Bluetooth, auto-standby) supports a "clean" installation: signal processing and management are handled upstream (amplification, matrix, processor), while the speaker focuses on the essentials: acoustic reproduction.
Who Is It For and What Are Its Uses?
This speaker is recommended if you are looking for a passive wall speaker capable of delivering both background music and voice announcements (paging, microphone, information), with a stated frequency response of 55 Hz to 20 kHz. Its 8-inch driver provides substance in the low-midrange, useful for maintaining presence at moderate volume, while the 1.4-inch tweeter contributes to intelligibility.
It is particularly suitable for integrators, installers, and operators who want to standardize a speaker fleet across multiple zones. Thanks to its 100 V compatibility (direct mono power 100 V: 60 W), it can be integrated into a multi-speaker distribution network, while remaining operable at 8 ohms depending on the chosen architecture.
Technical specifications
| Type | passive speaker | Impedance | 8 Ω |
| 100 V direct mono power | 60 W | Mixer | No |
| Number of channels | 2 channels | SPL Max / peak | 119 dB |
| Recommended amps | 400 W | Frequency response | 55 Hz - 20 kHz |
| Auto-standby | No | Input sensitivity (1W/1m) | 90 dB |
| Bluetooth | No | Speaker structure | ABS |
| Connection | Euroblock | Color | Black |
| Custom RAL | No | Index of protection (IP) | IP54 |
| Speaker diameter | 8" | Power output | 200 W |
| Tweeter | 1,4" | Power / type | RMS |
| Horizontal dispersion in degrees | 105.0000 | Mounting | wall-mounted |
| DSP | No | Weight | 11 kg |
| EQ | No | Dimensions (mm) | 440 x 254 x 251 |
