A Classic from the "Colette" Series, Built to Last
The modular "Colette" series from Schoeps has become a benchmark for demanding recording. In this stereo set, each MK 4 capsule is delivered with a pairing certificate, and its response curves are archived at the factory. This traceability facilitates maintenance and guarantees, for years, the performance level that has made the brand renowned.
Who Is This Matched Stereo Kit For?
For sound recordists and engineers who want a coherent cardioid pair for music, ambiance, events, or post-production. Ideal for stereo pairs of the X/Y, ORTF, NOS, or DIN type, it offers a precise image, very neutral sound coloration, and quick setup thanks to the included accessories.
Features and Key Points for Sound Recording
The MK 4 capsule combined with the CMC 6 amplifier delivers a wide frequency response and high dynamic range, with a 20 Hz (12 dB/oct.) low-cut filter to contain sub-bass and handling noise. Schoeps RFI shielding ensures exemplary immunity to modern interference. The balanced XLR output and high common-mode rejection maintain an excellent signal-to-noise ratio, even with cable runs over 400 m. This complete and robust stereo set is a sustainable professional solution for any stereophonic configuration.
Technical specifications
| Frequency response | 20 Hz - 20 kHz | Connection | XLR |
| Category | studio microphone | Color | Grey |
| Directivity | cardioid | ||
| Maximum sound pressure level (THD < 0.5%) with MK 4 | 131 dB SPL (P48, P12) | Schoeps RFI shield | yes |
| Maximum output voltage | 1 V (0 dBV) with 1 kilohm load | Power standards | P48 (20-52 V) or P12 (10-13 V) |
| Low-cut filter | 20 Hz, 12 dB/oct. | Current consumption | 4 mA (P48), 8 mA (P12) |
| Recommended minimum load impedance | 1 kilohm | Output | XLR-3M, analog, 1 channel per microphone |
| Output impedance | 42 ohms | Dimensions | 116 x 20 mm |
| Common-mode rejection ratio (at 1 kHz) | > 55 dB | Weight | 60 g |
| Maximum cable length | > 400 m (approximately 1,300 feet) | ||
Questions frequently asked
Is the Schoeps Stereo Set CMC6 MK4 suitable for ORTF and X/Y stereo recordings?
The matched pair of MK 4 cardioid capsules is suitable for X/Y, ORTF, NOS, and DIN configurations. Each capsule is delivered with a matching certificate and its frequency response curves are archived at the factory.
What phantom power is required for the CMC 6?
The accepted power supply is P48 from 20 to 52 V or P12 from 10 to 13 V. The consumption is 4 mA on P48 and 8 mA on P12.
What is the polar pattern of the MK 4 capsules?
The MK 4 use a cardioid polar pattern and cover a frequency response from 20 Hz to 20 kHz.
Is the high-pass filter integrated?
A high-pass filter at 20 Hz with a 12 dB per octave slope is integrated to reduce sub-bass and handling noise.
Can long XLR cables be used with this stereo pair?
The balanced output is on XLR with an output impedance of 42 ohms. Cable lengths over 400 m are recommended. The common mode rejection ratio exceeds 55 dB at 1 kHz and the Schoeps RFI shielding is present.
