Soundcraft Epm 12
Estimated Shipping Widget will be displayed here!
- This item is covered for 3 years
Couldn't load pickup availability
Information
Information
Manufacturer Information
Soundcraft
https://www.soundcraft.com
------------------------
Safety manager:
CSI audiovisuel
Email:
Address:
Essential Information About the EPM12 Mixing Console
- 12 mono + 2 stereo channel architecture with 2 auxiliaries and 60 mm faders for precise mixing.
- GB30 microphone preamps with 48V phantom power and a dynamic range of +22 dB.
- 3-band equalization with variable mid and insert points on all channels + Master.
- 8U rack-mountable chassis with included brackets, 10-segment stereo Master VU meter, and headphone output.
An EPM Series Designed to Offer the Best Performance/Price Ratio
Available in 6, 8, and 12 channels, the "EPM" series brings modern features to multi-format consoles without sacrificing accessibility. The use of low-tolerance surface-mounted components improves the accuracy of gain and correction circuits. The GB30 preamps, inherited from higher-end models, provide comfortable headroom and professional 48V phantom power.
Who Is It For and What Are Its Uses?
The EPM12 is aimed at bands, small stages, multipurpose rooms, and project studios seeking a reliable, intuitive, and quiet mixer. Its two auxiliaries facilitate monitor and effects management, while the inserts on each channel and the Master allow easy integration of compressors or external processors.
Technical specifications
| Type | analog Compact | Rackable | Yes |
| Number of faders | 13 | Headphone output | Jack 6.35, Yes |
Questions frequently asked
Does the Soundcraft EPM 12 have a 48 V phantom power supply?
A professional 48 V phantom power supply is built-in for microphones that require it. The GB30 mic preamps provide ample headroom.
Can external compressors be connected to this console?
Insert points are available on each channel as well as on the master. It is therefore possible to integrate external compressors or processors into the signal path.
What equalization settings are available on the mono channels?
Each mono channel offers a 3-band EQ with highs at 12 kHz and lows at 80 Hz, adjustable ±15 dB. The sweepable midrange covers 150 Hz to 3.5 kHz, with ±15 dB gain and a Q factor of 1.5.
Is this mixer suitable for stage monitors and effects?
The two auxiliary sends allow management of stage monitors and effects. This setup meets the needs of bands, small stages, and multipurpose rooms.
Can the console be rack-mounted and what power supply does it use?
References RW5736EU and RW5746 correspond to the EPM12 console with rack ears. The internal power supply accepts 85 to 270 V AC at 50/60 Hz, with a consumption below 35 W. No external power supply unit is required.
