Allen & Heath ZED14

A ZED Designed for the Field: Compact, Reliable, with the "Allen & Heath" Signature

Part of the ZED series, the ZED-14 embodies the core of Allen & Heath's approach: meticulous preamplification, effective equalization, and a build designed to last. Its compact chassis makes it easy to position on a small stage, in a home studio, or at the heart of a fixed installation, while maintaining connectivity worthy of a control room. The result: a versatile analog mixing tool, ready for daily demands (quick setups, dense cabling, rehearsals, performances).

An Ideal Console for Bands, Service Providers, and Personal Studios

The ZED-14 is aimed at small bands, solo artists, audiovisual service providers, places of worship, and personal studios needing multiple inputs without the bulk of a large console. It is perfectly suited for setups with vocal mics, instruments, stereo keyboards, and playback sources, while providing enough to manage stage monitors and external effects.

Its stereo USB interface simplifies recording and playback from a computer: convenient for capturing rehearsals, streaming backing tracks, or retrieving a stereo mix without adding a dedicated interface.

Technical specifications

Insert	Yes	Number of mic preamps	6
Number of faders	12	Recording	USB
Number of channels	14	Number of auxiliary sends	4
Phantom power supply	Yes	Mic inputs	6 x XLR
Bluetooth	No	Line inputs	4 x stereo, 6 x jack mono
EQ	3-band with semi-parametric mid and 3-band per channel	Inputs (other)	USB, inserts : jack for each mono input, 2 x phono
Motorised faders	No	Main outputs	mono jack, 2 x XLR
Filters	Low cut	Outputs (other)	USB, headphone 6,35 mm stereo jack, headphone 3,5 mm stereo jack, Record RCA, alternative (Rca), 2 x tracks (RCA)
PFL/AFL mode	Yes	Color	Grey
Rackable	Yes	Display	LED
Category	analog mixer	Weight	7.5 kg
Fader travel	100 mm	Dimensions (mm)	385 x 465 x 45

Mono inputs	6 balanced mic inputs on XLR / line inputs on 6.35 mm jack, with insert per channel	4 auxiliary sends	1 and 2 pre-fader (switchable to 2 mono or 1 stereo on the relevant channels), 3 and 4 post-fader
Mono input controls	shared 48 V phantom power switch, adjustable gain and low-cut filter	Per-channel controls	pan/balance, mute and PFL
Stereo line inputs	4 unbalanced inputs (1 x 6.35 mm jack per channel) with adjustable gain	Output level indicator	12-segment bargraph
Equalization	3-band EQ, including 1 semi-parametric band on the mono channels ; 2 fixed bands on the stereo channels	USB port	stereo send to PC \= L/R or Aux 1/2 or Aux 3/4
Effects returns	2 stereo returns, adjustable level and assignment to stereo channels deg1, deg2 or L/R bus	USB return	stereo to L/R or to stereo channel deg3
Additional inputs	2 x RCA, USB	Converters	16-bit, 32-48 kHz
Main output	stereo on 2 balanced XLR outputs with insert	Faders	12 ALPS 100 mm
Mono summing	output on an unbalanced 6.35 mm jack	Power supply	integrated 100-240 V, 50/60 Hz
Additional outputs	2 x RCA (recording), alternative RCA, 2-track RCA, USB	Dimensions	385 x 465 x 45 mm (front/rear height 45/100 mm)
Headphone outputs	6.35 mm and 3.5 mm jacks (L/R or PFL/AFL monitoring), adjustable level	Accessories included	Cakewalk SONAR X1 LE software, US power cord
