- Hybrid Workflow : analog console + 24-track recorder built-in + USB audio interface to switch from live to studio without changing setup.
- High Input Capacity : up to 16 mic/line inputs on XLR/6.35mm Jack, plus 22 line inputs on 6.35mm Jack, ideal for bands, rehearsals, and small stages.
- Precise and Comfortable Mixing : 100 mm faders, PFL/AFL with LED metering, subgroups and auxiliaries for clean monitor mixes and stem mixes.
- Modern Connectivity : stereo Bluetooth, MIDI, DAW control (HUI/MCU), and SD card recording (up to 512 GB).
Manufacturer Information
Tascam
https://www.tascam.eu
tascam-sales@teac.de
------------------------
Safety manager:
CSI audiovisuel
Email:
Address:
A "Console + Recording" Approach Designed for Today's Musicians
This mixer follows the tradition of performance-oriented analog consoles: immediate handling, dedicated controls, and clear routing. It adds a decisive advantage for modern productions: the ability to record and playback a multitrack project without a computer, then switch to USB interface mode to finalize mixing in software. The result: a unique hub for rehearsal, stage, preproduction, and home studio.
Intended Uses and User Profiles
With its numerous inputs and dedicated outputs, this mixer is perfect for bands (mic'd drums, multiple vocals, guitars, keyboards), rehearsal studios wanting to archive sessions, and sound engineers seeking a compact live recording solution. It is also relevant for content creators who need a clean stereo mix, independent headphone monitoring, and reliable SD card recording, while retaining the option to integrate a DAW when the project requires it.
Technical specifications
| Type | analog Compact | Rackable | No |
| USB stereo recording / playback | Yes | Headphone output | Jack 6.35, Yes |
| Number of faders | 22 | ||
| Integrated 24-track recorder | 12 mono channels and 5 stereo channels plus stereo bus | Aux outputs | 5 on balanced 6.35 mm jacks |
| USB audio interface | 24 inputs and 22 outputs | Metronome output | 1 on 6.35 mm jack |
| DAW control | transport and recording via HUI/MCU | MIDI output | 5-pin DIN |
| Microphone/line inputs | 16 on XLR/6.35 mm jack combo sockets | Microphone preamps | 12 on XLR with Tascam Ultra HDDA technology (channels 1–12) |
| Line inputs | 22 on 6.35 mm jacks | Phantom power | +48 V, selectable in groups of 4 channels |
| Talkback microphone input | 1 on balanced 3-pin XLR | Loop paths (Send/Return) | input channels 1 to 12 and stereo bus |
| Footswitch input | 1 on 6.35 mm jack | Channel processing 1–12 | 100 Hz low-cut filter, one-knob compressor and 3-band EQ |
| MIDI input | 5-pin DIN | Stereo bus processing | 4-band digital EQ and compressor |
| Bluetooth receiver | wireless stereo sources, AAC and SBC codecs | Send routing | selectable Pre/Post EQ |
| Main output | 1 stereo on balanced 3-pin XLR | Effects processor | integrated, 16 effects (reverb, delay, chorus and others), fader control |
| Headphone outputs | 2 on 6.35 mm stereo jacks | 5 auxiliary sends | 4 auxiliary sends plus internal effect |
| Control Room output | 1 stereo on balanced 6.35 mm jacks | Recording media | SD, SDHC, SDXC cards (up to 512 GB, Class 10 or higher) |
| Sub outputs | 4 stereo on 6.35 mm jacks | Recording/playback formats | WAV (BWF format) 44.1/48 kHz, 16/24-bit |
You will also like
Yamaha
Tio 1608-D2
Solid State Logic
Big Six
Allen & Heath
DT168
Palmer
PPB 20S Pro
Dynacord
CMS 1000-3
Allen & Heath
DX164-W
Allen & Heath
WZ4-16-2
Allen & Heath
ZED428
Questions frequently asked
Can a full band be recorded without a computer?
The built-in recorder captures up to 24 tracks on SD, SDHC, or SDXC cards: 12 mono channels, 5 stereo channels, and a stereo mix. WAV/BWF files are recorded at 44.1 or 48 kHz with 16- or 24-bit resolution. Cards up to 512 GB with a minimum class 10 are supported.
Can the Tascam Model 2400 be used as a USB audio interface for a DAW?
Via its USB-B 2.0 port, the console functions as a 24-input, 22-output USB audio interface. DAW control via HUI/MCU allows transport and recording functions to be operated from the surface.
How many monitor mixes can be managed?
Five auxiliary sends are available, including four Aux sends and one dedicated send for the internal effects. Selectable Pre/Post EQ routing allows adapting sends for monitor mixes or external processing.
What processing is available on the mic inputs?
The 12 mono channels feature Tascam Ultra HDDA XLR mic preamps, a 100 Hz high-pass filter, a one-knob compressor, and a three-band EQ.
Does the console include effects and Bluetooth connectivity?
An internal effects processor offers 16 programs, including reverb, delay, and chorus. The AAC/SBC Bluetooth receiver allows adding a wireless stereo source.
