Essential Information About the Zoom LiveTrak L-20R Rackmount Multitrack Recorder / Mixer
• Ultra-practical 2U rack format: all the power of the LiveTrak series in a compact chassis, ideal for control rooms, mobile studios, and in-ear monitors.
• Custom monitor mixes: 6 balanced headphone/line outputs with individual mixing, in addition to the front-of-house mix and the sound engineer's headphone output.
• Stress-free control from iPad: Bluetooth control via the Remote Mixer app, with up to 6 additional iPads connected via WiFi so each musician can manage their own monitor mix.
• Simultaneous recording and audio interface: captures up to 22 tracks on SD card at 24/96 kHz and USB interface mode with 22 inputs / 4 outputs simultaneously.

Livetrak L-20R

666,00 €VAT incl.

0,90 € Ecotax included

Reference price

A "rack" version designed for the stage, without compromising the LiveTrak DNA

The LiveTrak L-20R retains the spirit of the console version but optimizes it for setups where space matters: rack mounting, fixed installation, touring fly-rack, or rehearsal control room. It features the same concept that made the "L" family successful: a solid front-of-house mix, independent monitor mixes, and a standalone multitrack recorder on SD card. The result: you centralize sound reinforcement, monitors, and recording with a single device that's easier to transport and integrate into an existing system.

Who the L-20R is for and in which applications it makes a difference

The Zoom LiveTrak L-20R is aimed at bands and technicians who want a reliable system to manage in-ear monitors, wedges, or headphones during rehearsals while maintaining the ability to record each source separately. In live settings, it simplifies monitor management thanks to 6 dedicated mixes, and in mobile studios, it becomes a quick solution to record a full session without a computer. Finally, in hybrid setups, you can record to SD while sending audio to your DAW via USB, convenient for securing takes or working in post-production.

iPad control, multiple monitors, and integrated processing: a modern workflow

Smooth mixing, even without a front-of-house console

The great strength of the L-20R is monitor and mixing management from iPad: the Master mixer is controlled via Bluetooth with the BTA-1 adapter, and up to 6 additional iPads can connect via WiFi to give each musician control over their personal mix. Fewer trips to the mixer, fewer compromises, and more autonomous musicians on stage.

Precise per-channel settings and ready-to-use effects

Each channel benefits from processing tools designed for speed and quality: variable high-pass filter to clean the lows, 3-band EQ with semi-parametric mid to sculpt each instrument's space, compression on channels 1 to 16 to stabilize vocals, bass, or guitar, and two internal multi-effects with 20 built-in effects to add depth without external gear. On the Master output, the 15-band graphic EQ helps adjust the sound system and tame problematic frequencies.

Standalone multitrack recorder + audio interface: total versatility

The L-20R records up to 22 simultaneous tracks on SD card, with playback of up to 20 tracks and an auto start/stop function that secures your recordings. At the same time, it can operate as a USB audio interface with 22 inputs / 4 outputs, allowing recording into a DAW, virtual soundcheck, or integrating playback monitors. The USB port also offers class-compliant mode for iOS compatibility, project import/export, card reader, and adjustable A/D latency settings.

Technical specifications

Type	digital Compact (Integrated Mixing Engine)
USB stereo recording / playback	Yes
Number of faders	0

Rackable	Yes
Headphone output	Yes

2 stereo inputs	2x mono jack, RCA, or USB
48 V phantom power	channels 1-16 in groups of 4
Hi-Z switch	channels 1 and 2
26 dB pad	channels 3 to 16

Main output	2x XLR
1 headphone output	Master / Monitor 1-6

Card compatibility

SD, SDHC, SDXC

Audio interface mode	22 inputs / 4 outputs
Class-compliant mode	iOS compatibility

Compression	channels 1 to 16
Settings via iPad Remote Mixer app	phase invert, variable high-pass filter (40-600 Hz), 3-band EQ with semi-parametric mid, pan, sends to two internal multi-effects
2 internal multi-effects	20 built-in effects
15-band graphic EQ	Master output
Mute and Solo switches	on each channel, including effects return and Master
Recorder control	transport
Settings save	up to 9 scenes

Questions frequently asked

How many tracks can be recorded simultaneously on the Zoom LiveTrak L-20R?

The built-in recorder captures up to 22 tracks simultaneously on SD, SDHC, or SDXC cards. Playback can reach up to 20 tracks, with auto start and stop functionality.

Can separate in-ear monitor mixes be managed with this rack mixer?

Six dedicated monitor mixes allow feeding personal in-ear returns. Up to 6 additional iPads can control these mixes via WiFi.

Does control from an iPad require an accessory?

Master mixer control from the iPad is done via Bluetooth using the Zoom BTA-1 adapter.

What USB audio interface capabilities are available?

Via USB, the device functions as a 22-input and 4-output interface for DAW recording. The class-compliant mode ensures iOS compatibility. Audio can be sent to a computer while simultaneously recording to an SD card.

What microphone inputs and processing are available?

The 16 channels have 48 V phantom power provided in groups of 4, while inputs 1 and 2 offer a Hi-Z mode. Compression is available on channels 1 to 16, with a variable high-pass filter and 3-band EQ controllable from the iPad app.
