Essential Information About the AFX HotBeam-3R Moving Head
Essential Information About the AFX HotBeam-3R Moving Head
- Versatile 3-in-1: instantly switches from sharp "beam" to precise "spot" to even "wash," ideal for covering all stages.
- Comprehensive effects engine: dual gobo wheels (14 static, 9 rotating), 13-color + white wheel with rainbow effect, 8-facet rotating prism and 6-facet linear prism, frost filter.
- Professional control: 16 or 24 DMX channels, Auto, Musical, Master-slave, and Manual modes, motorized focus and zoom for fast and polished creations.
- Fast and smooth: 3-phase motors, 540deg pan and 270deg tilt, reversible high-resolution LCD display for use on truss or inverted mounting.
Manufacturer Information
Afx Light
https://www.lotronic.net
webshop@lotronic.net
------------------------
Safety manager:
Lotronic Belgique
Email: webshop@lotronic.net
Address:
From Private Parties to Large Stages: One Moving Head to Do It All
Designed for modern events, the HotBeam-3R covers all lighting needs: tight beams that cut through club haze, readable "spot" textures for concerts or sets, and color "wash" to even out a stage or dancefloor. Its DMX-controlled zoom and focus allow seamless scene changes without swapping fixtures, whether for mobile gigs, theaters, bars/restaurants, weddings, or corporate events.
Who Is This 3-in-1 Moving Head For?
The HotBeam-3R is aimed at mobile DJs and service providers who want to carry a single versatile moving head capable of everything, as well as lighting technicians and club operators seeking an agile and expressive lighting base. Theaters and rental companies will appreciate its clear menu logic, reversible display, and fast mechanics for efficient setup and teardown.
Technical specifications
| Spotlight type | Hybrid | ||
| Lamp type | 3R discharge | Prisms | 8-facet rotating, 6-facet linear |
| Lamp model | YODN150MSD3R | Pan | 540deg |
| Lamp power | 150 W | Tilt | 270deg |
| 3-in-1 function | beam, spot, wash | Motors | 3-phase |
| Focus | DMX-adjustable | DMX control | 16 or 24 channels |
| Zoom | DMX-adjustable | Operating modes | Auto, Musical, DMX, Master-slave, Manual |
| Frost filter | yes | Display | reversible high-resolution LCD |
| Static gobo wheel | 14 gobos + open | Power supply | 220-240V 50/60Hz |
| Rotating gobo wheel | 9 gobos + open | Power consumption | 230 W |
| Gobo shake function | yes | Dimensions | 333 x 323 x 540 mm |
| Colour wheel | 13 colours + white | Weight | 13 kg |
| Rainbow effect | yes | ||
You will also like
Algam Lighting
MH200
J.collyns
Pack Moving Head Spot 100W Primus
Cameo
Auro Spot Z300
Chauvet DJ
Intimidator Hybrid 251SR
Afx Light
MAGIC-WASH25
Power Lighting
Pack Moving Head Spot 100W Syrius
Showtec
Phantom 3R Hybrid
ADJ
Focus Spot 2X
Questions frequently asked
Afx Light HOTBEAM-3R: beam, spot, and wash in a single moving head?
The 3-in-1 function combines beam, spot, and wash modes around a 150 W 3R discharge lamp. Motorized zoom and focus allow adjusting the beam angle and sharpness of projection. A frost filter is included for the wash effect.
How many DMX channels does the HotBeam-3R use?
DMX control is available in 16 or 24 channels depending on the desired level of control. Parameters include zoom, focus, and pan movement over 540° and tilt over 270°.
Which gobos and prisms are included?
Two wheels contain 14 static gobos and 9 rotating gobos, each with an open position, while an 8-facet rotating prism and a 6-facet linear prism create multiple beams.
What are the weight and dimensions of this moving head?
Weighing 13 kg, this moving head measures 333 Ă 323 Ă 540 mm. Power consumption is 230 W with a 220-240 V, 50/60 Hz supply.
Can the HotBeam-3R be used without a DMX controller?
Auto, Music, Master-slave, and Manual modes allow operation without a DMX console. A reversible high-resolution LCD display facilitates settings when the moving head is rigged.
