A Green Laser Bar That Shapes the Stage Space
Designed to draw pure and perfectly parallel lines, the Laserworld BeamBar 10G instantly transforms a stage, dance floor, or entrance aisle into a true luminous corridor. Its 1-meter line distributes ten dense green beams that cut through smoke and haze, creating spectacular perspectives and a graphic "wall" ideal for highlight moments. In musical or standalone mode, it generates smooth and rhythmic sequences; in DMX mode, it integrates with timecode and your cues for precise shows during concerts, club nights, corporate events, or weddings.
Who Is the BeamBar 10G For?
This laser bar is aimed at mobile DJs who want a signature effect without deploying a large amount of equipment, lighting technicians and event service providers seeking a reliable and quick-to-deploy beam curtain, as well as club and venue operators looking for a strong visual identity element. It is also suitable for theatre companies and studios for graphic scenes, video credits, or striking backlighting.
Features and Innovations
At the heart of the BeamBar 10G, ten green semiconductor diodes at 520 nm deliver tight and homogeneous beams. The analog modulation accessible via DMX allows precise intensity control: gradual fades, nuanced strobes, and tempo-synced pulses maintain stable colorimetry without perceptible "steps." The automatic, musical, master-slave, and DMX modes cover all scenarios, from plug-and-play to advanced integration in a lighting console. The front-facing alignment screws facilitate optical calibration to achieve a straight curtain, perfectly parallel fans, or perspective effects depending on the chosen angle. Class 3B requires responsible operating practices: the bar comes with an interlock connector and key to secure on-site ignition and comply with current procedures.
Technical specifications
| Laser sources | semiconductor diodes |
| Color | green at 520 nm |
| Total guaranteed output power | 750 mW |
| Power per module | 10 x 75 mW (520 nm) |
| Beam characteristics | approx. 3.0 mm / 1.1 mrad |
| Laser alignment | front-facing adjustment screws |
| Operating modes | musical, standalone, DMX, master-slave |
| Laser class | 3B |
| Safety accessories | interlock connector and key included |
| Power supply | 100 V - 250 V AC, 50/60 Hz |
| Power consumption | 50 W |
| Dimensions | 1000 x 160 x 80 mm |
| Weight | 9.0 kg |
Questions frequently asked
What power and beam color does the BeamBar 10G MK3 offer?
The guaranteed total output power is 750 mW, distributed across ten 75 mW modules. The semiconductor diodes emit green light at 520 nm.
Can the laser bar be controlled via DMX?
DMX control is available, featuring analog modulation to adjust the beam intensity. Standalone, music-responsive, and master-slave modes are also provided.
How many green beams are produced?
Ten beams are distributed over a length of 1 meter. Each beam has characteristics of approximately 3.0 mm and 1.1 mrad.
What safety features are provided with this class 3B laser bar?
An interlock connector and a key are supplied to secure ignition. The class 3B laser classification requires responsible use and compliance with applicable procedures.
What are the dimensions and weight of the BeamBar 10G MK3?
The device measures 1000 x 160 x 80 mm and weighs 9.0 kg. Its power supply accepts 100 to 250 V AC at 50/60 Hz, with a consumption of 50 W. Adjustment screws on the front panel enable beam alignment.
