A Modern Condenser Designed in Silicon Valley
Born from a modern engineering approach, the Atlantis features a large 38 mm capsule, rare in its category, designed to reproduce the dynamics and texture of a performance. Its audiophile signal path-high-resolution polypropylene capacitors, US-made FET, and custom-wound output transformer-preserves transients while adding subtle harmonic density that naturally fits into a mix.
Who Is It For and What For?
Versatile by nature, the Atlantis is aimed at engineers, creators, and podcasters seeking a studio microphone ready for anything: lead vocals and voice-over, acoustic guitars, pianos, string ensembles, brass, or overheads. The three polar patterns adapt the sound capture to the room, while the built-in pads secure the recording of close or very loud sources without saturating preamps.
Features Designed for Demanding Sound Capture
Large-Diameter Capsule: the 38 mm diaphragm offers full bass, present midrange, and silky highs, with an easy-to-control proximity effect to shape vocal presence.
Quiet and Musical Electronics: the low-noise FET reduces hiss and maximizes signal-to-noise ratio, while the output transformer delivers balanced lows and a stable image, ideal for complex sources.
Immediate Control: with switchable polar patterns and -10 / -20 dB attenuation pads, the Atlantis transitions from intimate recording to high SPL capture in one gesture, while being simply powered by 48 V phantom power.
Technical specifications
| Frequency response | 20 Hz - 20 kHz |
| Category | studio microphone |
| Directivity | omnidirectional, cardioid, bidirectional |
| Capsule | Large Diaphragm |
| Connection | XLR |
| Color | Beige |
| Type | pressure gradient condenser |
| Large diameter capsule | 38 mm |
| Polar patterns | cardioid, omnidirectional, figure-8 |
| Attenuation pad | -10 dB, -20 dB |
| Dynamic range | minimum 120 dB |
| Max SPL (0.5% THD at 1 kHz) | 120 dB (140 dB with -20 dB pad) |
| Equivalent noise level | below 20 dB(A) |
| Sensitivity | 16 mV/Pa (-36 dB +/-2 dB, 0 dB = 1 V/Pa at 1 kHz) |
| Output impedance | less than 200 ohms |
| Phantom power | 48 V required |
Questions frequently asked
What polar patterns does the Lauten Audio Atlantis FC-387 offer?
Three switchable polar patterns: cardioid, omnidirectional, and figure-8. This selection allows adapting the pickup to the source and the room acoustics.
Does this microphone require 48 V phantom power?
48 V phantom power is required via the XLR connection.
Can it record vocals or acoustic guitar?
The 38 mm large-diaphragm capsule is designed for lead vocals, voice-over, and acoustic guitars. Its frequency response ranges from 20 Hz to 20 kHz. The low-noise FET helps minimize hiss during detailed recordings.
What is the maximum sound pressure level this microphone can handle?
The maximum SPL reaches 120 dB at 0.5% THD at 1 kHz. With the -20 dB pad engaged, it increases to 140 dB. Two attenuation pads, -10 dB and -20 dB, are built in for loud sources.
What connectivity and sensitivity does the Atlantis FC-387 have?
The XLR output features an impedance below 200 ohms, with a sensitivity of 16 mV/Pa (-36 dB ±2 dB at 1 kHz).
