Mackie Onyx 12

Name: Onyx 12
Brand: Mackie
SKU: 343950
Price: 495.00 EUR
Availability: InStock
Rating: 4.67 (3 reviews)

495,00 €VAT incl.

0,90 € Ecotax included

Reference price

In stock online

In stock in store

Estimated Shipping Widget will be displayed here!

ID : 343950

EAN : 0663961060942

This item is covered for 3 years

Information

Essential Information About the Mackie Onyx 12 Mixing Console
• Onyx Preamps with very low noise offering up to 60 dB of gain for clean and powerful recordings.
• 12x4 USB Interface at 24-bit/96 kHz + direct SD card recording/playback for flexible capture.
• Studio Command Color Display and illuminated buttons for clear control even on dark stages.
• Perkins "British style" EQ and customizable built-in effects processor with 6 user presets.

Onyx 12

495,00 €VAT incl.

0,90 € Ecotax included

Reference price

The Onyx DNA, a Modern Classic

True to Mackie's philosophy, the Onyx 12 combines the warmth of an analog console with the flexibility of a modern recorder. The Perkins EQ, inspired by prestigious British desks from the 60s/70s, delivers broad and precise musicality, while the Onyx preamps ensure ample and quiet gain headroom.

For Stage, Home Studio, and Streaming

Whether you're mixing a concert, producing in a home studio, or streaming live, the Onyx 12 serves as a reliable audio hub. Its generous connectivity, Bluetooth for background music, and USB multitrack recording simplify both soundchecks and post-production.

Technical specifications

Insert	Yes	Busses / groups	2 sub-groups
Number of faders	16	Number of auxiliary sends	3
Number of channels	8	Mic inputs	7 x XLR
Phantom power supply	Yes	Line inputs	14 x balanced jacks
Motorised faders	No	Inputs (other)	USB, minijack
Provided software	Tracktion Waveform	Main outputs	2 x XLR, 2 x balanced jacks
Rackable	Yes	Outputs (other)	monitor 2 x balanced jacks
Rack unit	14	Color	Black
Category	USB console	Built-in effects	Yes
Fader travel	60 mm	Display	OLED
Number of mic preamps	8	Weight	5.8 kg
Recording	USB, SD card

Questions frequently asked

Does the Mackie Onyx 12 allow multitrack recording on a computer?

The USB port supports 12x4 multitrack playback and recording up to 24-bit/96 kHz. USB returns are assigned to channels 9/10 and 11/12. Waveform OEM software and the Mackie Musician collection of 23 plug-ins are included.

How many microphones can be connected to this mixer?

This mixer features 7 XLR mic inputs and 8 Onyx preamps. Phantom power is available for microphones requiring this type of power supply.

Is it possible to record directly to an SD card?

Stereo recording and playback on an SD card are supported, with a return on channel 7/8.

What outputs are available for the front panel and monitor mixes?

The main L/R outputs are provided on balanced XLR and 6.35 mm TRS jacks, with a 12-segment LED meter. A Control Room output is available on two balanced 6.35 mm TRS jacks. The headphone output uses a 6.35 mm jack with volume control.

What sound settings and effects are integrated?

Each channel features a Perkins 3-band EQ with semi-parametric mids and a 100 Hz high-pass filter. Built-in effects are accessible via the OLED Studio Command screen, which allows saving 6 user FX presets.
