Mackie Pro FX 16 V3
Estimated Shipping Widget will be displayed here!
- This item is covered for 3 years
Couldn't load pickup availability
Information
Information
Manufacturer Information
Mackie
https://www.mackie.com
------------------------
Safety manager:
Algam SAS
Email: contact@algam.net
Address:
Essential Information About the Mackie ProFX16v3 Mixing Console
- 16 channels with 11 very low-noise Onyx mic preamps, gain up to 60 dB
- USB 24-bit/192 kHz 2x4 interface for recording and creating two separate monitor mixes
- GigFX effects engine with 24 presets and footswitch mute
- Full routing: 2 subgroups, 4 auxiliary sends (3 monitor + 1 FX), inserts on 1-8, 3-band EQ with semi-parametric mids
A Reliable Choice in the ProFX Series, Designed for Stage and Studio
Designed for versatility and reliability, the ProFX16v3 continues the tradition of Mackie's steel-chassis " Built-Like-A-Tank " consoles. It combines the ruggedness required for live performance with modern production features, making it a staple in concert sound setups, home studios, and creative spaces.
For Live, Home Studio, Podcasting, and Streaming
Whether mixing a band, producing a podcast, or streaming, its zero-latency direct monitoring and Hi-Z inputs allow you to connect guitars or basses without a DI box. The monitor source switch instantly toggles between computer playback and direct signal, ideal for precise overdubs.
Technical specifications
| Insert | Yes | Number of auxiliary returns | 4 |
| Number of faders | 16 | Recording | USB |
| Number of channels | 16 | Busses / groups | 2 sub-groups |
| Phantom power supply | Yes | Compressor / gate | channels 1 to 8 |
| Motorised faders | No | Number of auxiliary sends | 4 |
| Filters | 100 Hz low cut | Line inputs | 12 x balanced jacks |
| Provided software | Tracktion | Inputs (other) | USB, minijack |
| PFL/AFL mode | Yes | Main outputs | 2 x XLR, 2 x balanced jacks |
| Rackable | Yes | Outputs (other) | headphone 6,35 mm stereo jack, 2 x sub-groups 2 x balanced jacks, 4 x Aux unbalanced Jacks, 2 headphones channels with jack and minijack outputs |
| Rack unit | 17 | Color | Black |
| Category | mixer | Display | Meter |
| Number of mic preamps | 11 | Weight | 6.9 kg |
Questions frequently asked
Does the Mackie ProFX16v3 serve as a 2x4 USB audio interface?
The 2x4 USB interface supports 24-bit / 192 kHz playback and recording. Two separate software mixes can be sent back to the mixer.
How many microphones can be connected to this mixer?
The 11 Onyx mic preamps accommodate microphones requiring a high gain range. Phantom power is built-in for compatible microphones.
Can a guitar be plugged directly into the mixer?
The Hi-Z inputs allow direct connection of a guitar or bass without a DI box.
How many stage monitors and effects sends are available?
There are four auxiliary sends: one FX send and three monitor sends. The monitor sends can be set pre- or post-fader per channel. The GigFX processor offers 24 effects, with a footswitch mute function.
What are the dimensions and weight of the mixer?
Measuring 434 x 450 x 112 mm, the mixer weighs 6.9 kg. Its Built-Like-A-Tank steel chassis is rack-mountable at 17 units.
