Hammond XK-4

A Modern Heir in the Hammond Lineage

The Hammond XK-4 stands as a modern synthesis of the Hammond spirit: a portable instrument designed for keyboardists who want the authenticity of a tonewheel organ without sacrificing editing comfort and the reliability of a stage keyboard. With its Modelled Tone Wheel 2 engine, it does not merely imitate a timbre: it reproduces the life, nuances, and behavior, while expanding the palette with transistor "combo" organ models (Italian, British, Japanese) and customizable classical and theater organ banks.

Keyboard Design

The XK-4 features a light-touch organ keyboard with virtual "multi-contact", designed to replicate the fast response and characteristic feel of historic Hammonds. The drawbars allow instant harmonic blending, while the programmable pitch bend and modulation wheels add contemporary expressiveness for studio and live contexts. The beech wood side panels complete an aesthetic faithful to the brand's DNA, blending tradition and performance instrument.

Sound Quality

Sound generation relies on MTW2 modeling, with precise work on the 91 tonewheels to achieve an organic, rich, and responsive sound. The digital Leslie aims for an immersive experience by modeling movement, speeds, and transitions, with fine control over ramps and mic placement to tailor the stereo image to your amp or front of house. To recapture the character of legendary machines, the XK-4 also includes tube modeling and an emulated matching transformer: enough to thicken the attack, enhance presence, and provide that "vintage" relief that makes a difference in a mix.

Built-in Effects

• Hammond Chorus/Vibrato (three generations) and Touch-Response Percussion
• Overdrive: Tube, Solid, Clip, EP Amp
• Multi-effects 1: Tremolo, Wah, Ring Modulator, Compressor
• Multi-effects 2: Phaser, Flanger, Chorus, Delay, Auto Pan
• Leslie: 8 models (including 122, 145, 147) with independent volume, Fast/Slow speeds, ramps, and mic placement
• Master EQ to adjust tonal balance according to room, amp, or PA system

Technical specifications

Effects	Wah, Tremolo, Delay, Compressor, Chorus, Leslie Simulator and Octaver, Overdrive, Flanger, Panning, Phaser, Ring modulation	Number of keys	61
Arpeggiator	No	Touch	Lightweight
Bluetooth	No	USB to Host port	Yes
Controller	Pitchbend, Modulation, Drawbars	Inputs	Expression pedal, Audio in, Control pedal
Number of speakers	0	Outputs	Leslie, USB Type B, Mono & stereo audio, 6.5 mm headphone, USB Type A
Velocity sensitive	Yes	Color	Black
MIDI DIN I/O	Yes	Finishing	Matt

Keyboard	lightweight organ keyboard with virtual multi-contact	Multi-effects 2	Phaser, Flanger, chorus, Delay, Auto Pan
Drawbars	traditional (drawbars)	Master EQ	yes
Wheels	programmable pitch bend and modulation	Modeling	tubes and matching transformer
Buttons/switches	assignable	Headphone output	HEADPHONE
Side panels	beech wood	Auxiliary input	AUX IN with dedicated volume control
Display	color	Leslie connector	11-pin, automatic deactivation of the digital Leslie when a Leslie speaker is connected
Sound engine	MTW2 modeling 91 tone wheels	Leslie switch connector	dedicated to the " Half Moon " CU-1 (optional)
Combo organ models	transistor, Italian, British, Japanese	USB	A/B, backup and direct MIDI connection to PC/Mac
Organ ranks	multiple, customizable classical organ and theatre organ	Recording	configurations, patches and customized tone wheels on a USB flash drive or computer
Percussion and Chorus/Vibrato	Touch-Response Percussion and Chorus/Vibrato (3 generations to choose from)	Power cable	standard IEC C14
Digital Leslie	8 models, speed, ramp and microphone position adjustment	Voltage selection	automatic according to the country
Overdrive	Tube, Solid, Clip, EP Amp	Dimensions	1004 x 322 x 109 mm
Multi-effects 1	Tremolo, Wah, Ring Modulator, Compressor	Weight	9.4 kg
